Copley Controls Accelnet Plus Dual-Axis Panel EtherCAT Manual page 32

Accelnet
dIMensIons: In (MM)
0.19 [4.8]
0.19 [4.8]
0.85 [21.5]
0.85 [21.5]
2.29 [58.1]
2.29 [58.1]
0.19 [4.8]
0.16 [4.1]
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Web: www.copleycontrols.com
Plus
2-Axis Panel EtherCAT
6.78 [172.1]
6.78 [172.1]
6.40 [162.4]
6.40 [162.4]
4.89 [124.3]
4.70 [119.3]
0.19 [4.8]
0.19 [4.8]
0.16 [4.1]
0.16 [4.1]
Mounting screws:
#6-32, or 3.5 mm
3.14 [79.98]
Tel: 781-828-8090
BE2
RoHS
units: In[mm]
Fax: 781-828-6547
Page 32 of 33
4.89
4.89
