Accelnet
deVIce structure & IsolatIon
This graphic shows the electrical structure of the drive, detailing the elements that share a common circuit
common (Signal Ground, HV Com) and circuits that are isolated and have no connection to internal circuits.
note that there is no connection between the heatplate (Chassis, frame Ground) and any drive circuits.
J11 HV & Aux
+
~
~
-
Earth
Ground
J5 Serial
J4 EtherCAT
X2 In and Out
Ports are Identical
EtherCAT
Connections are
isolated from
drive circuits
J1 Control
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
Web: www.copleycontrols.com
Plus
2
+HV
1
HV Com
3 DC-DC
Aux
Converter
Internal DC
Power for
5
All Circuits
TxD
4
3 Sgnd
2
RxD
Tx1+
75
Tx1-
1M
Isolated
10n
Rx1+
75
Rx1-
Vcc
Vcc
[IN1~4, 10~13]
[IN9,18]
Sgnd
Sgnd
[IN5~8,14~17]
Isolated
[AIN1~2+/-]
-
+
Sgnd
DRIVE CIRCUITS
BE2 Heatplate
2-Axis Panel EtherCAT
1360 µF
+
Inverter
HV Com
Gnd
Sgnd Inverter
Signal Gnd
Drive Control Core
Control Core circuits are
referenced to Signal
Ground (Sgnd)
and HV Com ground
Vcc
Vcc
Sgnd
Sgnd
HEATPLATE
Protective
Earth ground
Tel: 781-828-8090
BE2
J9 Axis A
4
PWM
3
2
1
J10 Axis B
4
PWM
3
2
1
Brk 24V Input
Isolated
Brk 24V Output
R-L
Brake A
R-L
Brake B
24V Return
J3 Brake
Vcc
J7,J8 Axes A,B
Vcc
Motor temp switch
[IN9,18]
Sgnd
[OUT1~5+]
J2 I/O
[OUT1~5-]
Fax: 781-828-6547
RoHS
Axis A
Motor
Frame Gnd
Axis B
Motor
Motor cable shield
connects to Frame Ground
Frame Gnd
+
+24V
-
