Figure 9. Unit component layout and "ship with" locations
Outside Air
Dampe rs
Re turn/
E xhaus t
Fan
V ariab le
F rquen cy
Outside Air
Drive (VF D)
Dampe rs
Figure 10. Space temperature averaging with
multiple sensors
Single Zone Averaging Circuit
Remote Sensor #1
Four Zone Averaging Circuit
Remote Sensor #1
Nine Zone Averaging Circuit
Remote Sensor #1 Remote Sensor #2
Remote Sensor #4 Remote Sensor #5
Remote Sensor #7 Remote Sensor #8
RT-SVX24Q-EN
Supply Fan
V ariab le
F rquen cy
Drive (VF D)
Out side Air
Static Kit and
sen sors
To Terminals
on the Zone Sensor
Module or to 1TB4
Remote Sensor #2
Remote Sensor #4
To Terminals
on the Zone Sensor
Module or to 1TB4
Remote Sensor #3
Remote Sensor #6
Remote Sensor #9
To Terminals
on the Zone Sensor
Module or to 1TB4
Hea ting
S ec tion
Compress or
Flue Vent Ho t Water/Steam
Ac ce ss
Hy dronic Conne ction
Unit Control Modules
Unit control modules are microelectronic circuit boards
designed to perform specific unit functions. The control
modules, through proportional/integral control
algorithms, provide the best possible comfort level for
the customer. They are mounted in the control panel
and are factory wired to their respective internal
components.
The control modules receive and interpret information
from other unit modules, sensors, remote panels, and
customer binary contacts to satisfy the applicable
request for economizing, mechanical cooling, heating,
and ventilation. The figure below illustrates the typical
location of each designated module.
G G e e n n e e r r a a l l I I n n f f o o r r m m a a t t i i o o n n
Condens er
F ans
Sect ion
