Table 51. Energy recovery wheel component static pressure drops — air-cooled and evaporative condensing — low
CFM (continued)
Nom Tons
CFM
AC/EC
Damper Open
9000
12000
16000
20000
23000
26000
150/162
30000
35000
40000
45000
50000
55000
58000
Table 52. Energy recovery wheel component static pressure drops — air-cooled and evaporative condensing —
standard CFM
Nom Tons
CFM
AC/EC
Damper Open
Standard CFM Energy Recovery Wheel
8000
9000
10000
12000
14000
16000
90/100
18000
20000
25000
30000
33000
36000
40000
9000
12000
14000
16000
19000
21000
105/118
23000
28000
33000
38000
43000
45000
RT-SVX24Q-EN
Outside Air Outside Air
Bypass Bypass
Damper Closed
Low CFM Energy Recovery Wheel
0.09 0.71
0.15 0.97
0.25 1.34
0.36 —
0.46 —
0.57 —
0.72 —
0.93 —
1.16 —
1.40 —
1.67 —
1.95 —
2.12 —
Outside Air Outside Air
Bypass Bypass
Damper Closed
0.06 0.54
0.08 0.61
0.10 0.68
0.15 0.83
0.19 0.99
0.24 1.16
0.30 1.32
0.35 -
0.52 -
0.70 -
0.82 -
0.95 -
1.12 -
0.08 0.57
0.14 0.77
0.19 0.93
0.24 1.08
0.32 1.33
0.37 1.49
0.44 -
0.61 -
0.80 -
1.00 -
1.23 -
1.33 -
Exhaust Air Exhaust Air
Bypass Bypass
Damper Open Damper Closed
0.10 0.62
0.18 0.92
0.28 1.33
0.40 —
0.49 —
0.60 —
0.75 —
0.97 —
1.20 —
1.43 —
1.69 —
1.96 —
2.12 —
Exhaust Air Exhaust Air
Bypass Bypass
Damper Open Damper Closed
0.07 0.44
0.10 0.53
0.12 0.62
0.17 0.77
0.22 0.94
0.26 1.12
0.31 1.29
0.37 -
0.54 -
0.73 -
0.84 -
0.97 -
1.14 -
0.09 0.47
0.16 0.65
0.21 0.78
0.26 0.91
0.34 1.11
0.40 1.25
0.46 -
0.64 -
0.82 -
1.03 -
1.25 -
1.34 -
