General Information

Unit Nameplate

One Mylar unit nameplate is located on the outside
upper left corner of the control panel door. It includes
the unit model number, serial number, electrical
characteristics, weight, refrigerant charge, unit wiring
diagram numbers, as well as other pertinent unit data.
A small metal nameplate with the Model Number,
Serial Number, and Unit Weight is located just above
the Mylar nameplate, and a third nameplate is located
on the inside of the control panel door.

Compressor Nameplate

The Nameplate for the Scroll Compressor is located on
the compressor lower housing. Max amps is listed on
the nameplate and is the absolute highest amp load on
the compressor at any operating condition (does not
include locked rotor amps or inrush). This value should
never be exceeded.

Unit Description

Table 1. Available tonnages
Air-Cooled Tonnages
90
105
120
130
150
Each single-zone rooftop air conditioner ships fully
assembled from the factory. An optional roof curb,
specifically designed for the S_HJ units is available
from Trane. The roof curb kit must be field assembled
and installed according to the latest edition of the roof
curb installation manual.
Trane Commercial Rooftop Units are controlled by a
microelectronic control system that consists of a
network of modules and are referred to as Unit Control
Modules (UCM). The acronym (UCM) is used
extensively throughout this document when referring
to the control system network. These modules through
Proportional/Integral control algorithms perform
specific unit functions which provide the best possible
comfort level for the customer.
They are mounted in the control panel and are factory
wired to their respective internal components. They
receive and interpret information from other unit
modules, sensors, remote panels, and customer binary
contacts to satisfy the applicable request for
economizing, mechanical cooling, heating, and
10
Evaporative Condenser
Tonnages
100
118
128
140
162
ventilation. Refer to the following discussion for an
explanation of each module function.
Table 2. Resistance input vs. setpoint temperature
RTM cooling or RTM cooling
heating setpoint input
setpoint input used as the
used as the source for
source for a SUPPLY AIR
ZONE temp temp setpoint
setpoint (°F) cooling (°F)
40
45
50
55
60
65
70
75
80
n/a
n/a
Table 3. RTM resistance value vs. system operating
mode
Resistance applied
to RTM MODE input
Terminals (Ohms)
Max. Tolerance 5%
2320
4870
7680
10770
13320
16130
19480
27930

Rooftop Module

(RTM - Standard on all units)
The rooftop Module (RTM) responds to cooling,
heating, and ventilation requests by energizing the
proper unit components based on information received
from other unit modules, sensors, remote panels, and
customer supplied binary inputs. It initiates supply fan,
exhaust fan, exhaust damper, positioning or variable
frequency drive output, and economizer operation
based on that information.
Resistance
(Ohms) Max.
Tolerance 5%
40 1084
45 992
50 899
55 796
60 695
65 597
70 500
75 403
80 305
85 208
90 111
Constant Volume Units
System Mode
Fan Mode
Auto Off
Auto Cool
Auto Auto
On Off
On Cool
On Auto
Auto Heat
On Heat
RT-SVX24Q-EN
