Figure 119. 130 ton eFlex variable speed—circuit 1 and circuit 2 operating pressure curve (compressor at 100% and all
condenser fans ON) (high capacity)
130 Ton eFlex Circuit 1, 50Hz High Capacity
550
500
450
400
350
300
250
90 100
130 Ton eFlex Circuit 2, 50Hz High Capacity
550
500
450
400
350
300
250
90 100
RT-SVX24Q-EN
110 120 130 140
Suc on Pressure, PSIG
110 120 130 140
Suc on Pressure, PSIG
o
105 F Ambient
o
95 F Ambient
o
85 F Ambient
o
75 F Ambient
o
65 F Ambient
150 160 170 180
o
105 F Ambient
o
95 F Ambient
o
85 F Ambient
o
75 F Ambient
o
65 F Ambient
150 160 170 180
U U n n i i t t S S t t a a r r t t u u p p
