TECHNICAL SPECIFICATIONS

Input Voltage: 100V~240V AC, 50/60Hz
Power Consumption: 480W
Power Connection: fixed
Fuse: 5AT
Light Source: 936 pcs 0.5W 6500K SMD5730 Cool White LED
Beam Angle: 120°
Output: 1450 lux @3M
PWM: 2000Hz
LED Lifespan: 50,000 hours
Dimming: 0 – 100%
Strobe: 0.5 – 23 Hz
DMX Protocol: DMX512
DMX Channel Mode: S4 / D4 / 6 / 10
DMX Interface: 3-pin XLR
Built-in Programming: Yes
Display: 4-button LCD control panel
Cooling: Sensor thermostat controlled variable speed fan
Housing Materials: ABS & steel
Housing Finishing: Matte Black
Net Weight: 6 kg
Overall Size: 425 x 215 x 125 mm
WARRANTY
Please refer to your local dealer or please contact Event Lighting Pty Ltd
Website: www.event-lighting.com.au.
