Dmx Chart - Event Lighting StrobeX User Manual

DMX Address
After select the "Address" and press "Enter", use "Up" and "Down" button to select the desired DMX address, press
"Entre" to save new setting.
DMX Modes
After select the "Channel" and press "Enter", use "Up" and "Down" button to select the desired DMX channel mode,
press "Entre" to save new setting.
Manual Mode
After select the "Manual" and press "Enter", use "Up" and "Down" button to select the block intensity from 000 to 255.
Then select strobe speed from 000 to 255, press "Enter" to save new setting.
Auto Mode
This fixture has 18 built-in programs. Entered "Auto" mode, use "Up" and "Down" button to select the built-in programs
"Auto 1 ~ Auto 18", then press the "Enter" to confirm. Use "Up" and "Down" button to select the operating speed of the
program from 000 to 255, press "Enter" to save new setting. You have to use "Effect on Auto" mode to adjust the
brightness and add strobe effect to auto run.
Effect on Auto
Use "Effect on Auto" to switch on dimmer and strobe function to auto mode. Entered "Effect on Auto" mode, use "Up"
and "Down" button to select dimmer level, then press the "Enter" to confirm. Use "Up" and "Down" button to select
strobe speed from 000 to 255, press "Enter" to save new setting.
Master/Slave Mode
Set the master fixture to auto or manual modes.
Entered "Master" mode, use "Up" and "Down" button to select "No", press "Enter" to set fixture to slave mode.
Use DMX to link master and slave fixture together.
DMX Data
When there is a '*' flashing, the StrobeX is not receiving any DMX signal. A solid '*' indicated DMX signal is being
received. DMX takes priority over all other functions when a signal is being received.
Once DMX signal is lost, the StrobeX will revert back to the original setting, which also could be DMX or Manual or
Automatic mode.

DMX Chart

S4 channels Mode
Channel Value
1 000-005
006-255
2 000-005
006-255
3 000-005
006-255
4 000-005
006-255
www.event-lighting.com.au
Function
No Function
Block 1 strobe slow to fast
No Function
Block 2 strobe slow to fast
No Function
Block 3 strobe slow to fast
No Function
Block 4 strobe slow to fast
4
