AMP Research PowerStep Installation Manual page 5

Locate mounting points. Frist middle and last set of holes on the inner sill. Install 5 u nuts (16) in upper mount
holes.
Rear Linkage
Bracket
1
Set Brackets into position and use provided M8 Bolts (21) and washers (15) on outside and provided M8
nuts on the backside. Do not tighten.
2
Using provided captive washer m8 bolts (8) install
upper bracket hardware to brackets. Do not tighten.
3
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P
Center Rail
Bracket
Front Linkage
Bracket
8
8
– F O R D F 1 5 0
T M
15 & 21
Set Rail up into position. Start with rear bracket work
towards the front brackets. Attach Carriage bolts 5x
(17) and Flange Nut 5X (18). Center rail at front and
rear door line. Torque Flange Nuts to 16 ft-lbs. Insert
Flange bolt (13) and nut (18) into side of bracket. Do
13
9
Note: Badge on rail sits towards the rear of vehicle!
4
5/10
15 & 21
18
8
18
IM77105 rev 01.13.20
17
