AMP Research PowerStep Installation Manual page 4

11
10
x6
M5 Hex Bolt
M5 Washer
16
15
x10
M8 U-Nut
M8 Washer
20
x20
Cable tie (7")
25
x4
LED Light
Bracket
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P
12
x6
x4
M6 Flange Bolt
17
x10
5/16-18
Carriage Bolt
21 22
x10
M8 Hex Bolt
Cable tie (11")
26
x4
Linkage Mounting
Bracket
13
x6
5/16 Flange Bolt
18
x10
5/16-18
Flange nut
23
x2
LED Lamp
27
x2
Rail Mounting
Bracket
4/10
– F O R D F 1 5 0
T M
14
x8
Socket Cap Screw
19
x16
Upper Mount
Spacer
24
x4
Butt Connector
28
x2
Gear Cover
IM77105 rev 01.13.20
x4
x8
29
x2
Motor
