AMP Research PowerStep Installation Manual page 3

A
1
x2
Running board assembly
2
x2
Motor Linkage assembly
5
Controller STA
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P
F
(A) End cap left (x1)
(B) End cap right (x1)
(C) T-nut insert (x2)
(D) Socket cap screw (x2)
(E) End cap wedge right (x1)
(F) End cap wedge left (x1)
3
Idler Linkage assembly
6
Wire harness
– F O R D F 1 5 0
T M
x2
8
7
x4
M8 Hex Bolt w
Posi-Tap™
Conical washer
3/10
C
E
D
B
4
x2
Rail Assembly
9
x18
M8 Nut w Conical
washer
IM77105 rev 01.13.20
x10
