APPLICATION
Ford F150 SuperCab
Ford F150 SuperCrew
SMART SERIES APP: Download
App to your phone and unlock
the latest features including
override, light controls, and
diagnostics.
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one OR MORE of the following patents:
6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,413,204; 7,398,985; 7,584,975; 7,566,064; 7,487,986; 8,157,277;
8,408,571; 9,302,626; 9,561,751; 10,053,017; CA2463717 ©2012 AMP Research. All rights reserved. Printed in USA.
www.amp-research.com
I N S T A L L A T I O N G U I D E
LENGTH
75"'
85"
1/10
MODEL YR
2015 - 2020
2015 - 2020
q Safety goggles
q 10 mm socket
q 13 mm socket
q 13 mm end wrench
q Ratchet wrench and extension
q Wire stripper
q 9/32" & 19/64" Drill Bit
q 3/16" hex key wrench ( allen wrench)
q 4mm hex key wrench ( allen wrench)
q Electrical tape
q Weather proof caulking (silicone sealer)
5-Year Limited Warranty
PART #
86151-01A
86151-01A
INSTALLATION TIME
2-3 Hours
Professional installation recommended
SKILL LEVEL
2
3
1
4= Experienced
TOOLS REQUIRED
WARRANTY
IM86151 rev 02.07.22
