Reznor RHC 8000 RJL Application Instructions page 8

Figure 3b: Back side view RHC 8125M, 8150M &8175M DJL/RJL
Figure 3c: Back side view RHC 8200M DJL/RJL
Type
8125M.15 1272
8150M.18 1481
8175M.21 1691
8200M.24 1900
0710RHC8-JLNLEN
Dimensions applicable to model RHC 8000M
(see fig. 1b/1c –2b/2c & 3b/3c)
A A1
183
183
183
133
(n° 59710_03)
(n° 59706_03)
RHC 8000 M DJL/RJL
A2 A3
1089 741
1298 741
1508 741
1767 950
A4 D
531 130
741 130
950 130
950 130
8/36
