Reznor RHC21 4000 Installation, Commissioning, Servicing

Gas fired air heater module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION / COMMISSIONING / SERVICING
EU)2016/426(GAR),2009/125/EC(ErP), 2014/35/EU(LVD),and2014/30/EU(EMC)
EN 17082, EN 60335-1, EN 60335-2-102, EN 55014-1, and EN 55014-2
Please read this document carefully before commencing installation, commissioning and/or servicing.
Leave it with the end user/site agent to be placed in their premises technical file after installation.
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death.
The manufacturer does not take any responsibility in the event of non-observance of the regulations concerning the connection of the apparatus causing a
dangerous operation possibly resulting in damage to the apparatus and/or environment in which the unit is installed.
MANUAL PART NO. D301334 ISS 0
RHC21 4000
GAS FIRED AIR HEATER MODULE
Regulations and Directives.
The following harmonised standards have been applied:
All work must be carried out by appropriately qualified persons.
WARNING
ErP Lot 21
ErP
Seasonal Efficiency
2021
and NOx compliant
