Original operating instructions
ZAtop – model series SM250.60B
5.4.2.2

Absolute encoder AE-SMRS64-BiSS-C

Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Housing
Table 5-4-2-2
5.4.2.3

Absolute value encoder type ERN1387

Pin
A
B
C
D
E
F
G
H
J
K
L
M
Table 5-4-2-3
5.4.3

Offset

" Unless otherwise agreed, the absolute encoder offset is set to 0 This is achieved by connecting DC
voltage with U to + and V and W to -.
" The absolute encoder may not be mechanically detached to ensure that the factory settings are not
lost. If the absolute encoder has been detached, a new absolute value encoder calibration must be
performed with the frequency inverter. For details of the procedure, refer to the frequency inverter
operating instructions.
A-TBA20_02-GB 2032 Index 003
Signal
DATA
DATA/
-
VCC
GND
-
B (sine)
-
CLOCK/
CLOCK
-
A (cosine)
A/ (cosine)
B/ (sine)
GND sense
-
Signal
C (cosine)
C/ (cosine)
D (sine)
5 V up
0 V un
B (sine)
D/ (sine)
R
R/
A (cosine)
A/ (cosine)
B/ (sine)
Part.-No. 01013399-GB (EU-BD 783)
Designation
Data line for communication with the absolute encoder
Data line inverse
-
Voltage supply
Ground power supply absolute encoder
-
Analog track B (sine)
-
Clock signal invers
Clock signal for serial transfer
-
Analog track A (cosine)
Analog track A invers (cosine invers)
Analog track B invers (sine invers)
Ground power supply absolute encoder
Shielding
Designation
Commutation signal (cosine)
Commutation signal inverse (inverse cosine)
Commutation signal (sine)
Controlled +5 V voltage supply (positive)
Ground voltage supply absolute encoder (negative)
Analog track B (sine)
Commutation signal (inverse sine)
Reference signal
Reference signal inverse
Analog track A (cosine)
Analog track A invers (cosine invers)
Analog track B invers (sine invers)
21/72
