  • Page 2: Table Of Contents

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Content General ..............Meaning of the operating instructions .
  • Page 3 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Absolute encoder ........... . . 5.4.1 Cable length .
  • Page 4 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure ..............Technical data .

  • Page 5: General

    Exclusion of liability ZIEHL-ABEGG SE is not liable for damage due to misuse, incorrect use, improper use or as a consequence of unauthorized repairs or modifications. Copyright These operating instructions contain copyright protected information.

  • Page 6: Pictographs

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Safety instructions Pictographs Safety instructions are highlighted with warning triangles and are depicted according to the degree of hazard as follows. Danger! General hazardous area. Death or severe injury or significant property damage can occur if the corresponding precautions are not taken! Warning! Risk of moderate or minor injury if the corresponding precautions are not taken!

  • Page 7: Operator's Obligation Of Diligence

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Safety instructions Warning! " " Depending on the operating conditions, the elevator machine can have high surface temperatures of > 80°C. Risk of burns! If the installation situation does not provide sufficient personal protection, then this must be provided by the customer in the form of additional measures.

  • Page 8: Employment Of External Personnel

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Product overview " " these personnel receive regular instruction in all relevant industrial safety and environmental protection issues and are familiar with the operating instructions and the safety instructions they contain "...

  • Page 9: Transport

    Imax - Acceleration current QR code Table 3-2 Transport • ZIEHL-ABEGG SE elevator machine are packed by the manufacturer for the types of transport and storage agreed upon. " " Transport the elevator machine in the original packing. " "...

  • Page 10: Storage

    - Turn motor shaft manually at least 3 turns in both directions to ensure even distribution of the bearing grease If you encounter any irregularities, please contact ZIEHL-ABEGG SE customer service. Disposal / Recycling Disposal must be carried out professionally and environmentally friendly in accordance with the legal stipulations.

  • Page 11: Fastening The Elevator Machine

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Mechanical installation Fastening the elevator machine " " On the bottom side of the socket are 4 threads. " " To attach the elevator machine, use exclusively the following screw types: 4 hexagon head screws ISO 4014 - M24 - 8.8 or 4 hexagon head screws ISO 4017 - M24 - 8.8 or 4 cheese head screws ISO 4762 - M24 - 8.8...
  • Page 12 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Mechanical installation Figure 4-5-01 - Rope guard " " The elevator machine is on the right and left fitted with rope guard (1). " " A 3rd rope retainer (2) is optionally available. "...

  • Page 13: Rope Guard Fastening In The Case Of A Traction Sheave Diameter Of 240 Mm

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Mechanical installation 4.5.1 Rope guard fastening in the case of a traction sheave diameter of 240 mm For wrap angle 180°. Figure 4-5-1-01 - Rope guard for traction sheave diameter 240 mm "...

  • Page 14: Rope Guard Fastening In The Case Of A Traction Sheave Diameter Of 520 Mm

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Mechanical installation 4.5.3 Rope guard fastening in the case of a traction sheave diameter of 320 mm and 400 mm Adjustability on both sides + 5°/- 30°. Normal wrap angles 30° - 185°. Figure 4-5-3-01 - Rope guard for traction sheave diameter 320 mm and 400 mm "...

  • Page 15: Patent Situation

    Compliance with the EMC directive 2014/30/EU only applies to this product if frequency inverters tested and recommended by ZIEHL-ABEGG SE are used and they are installed in line with the associated operating instructions and are EMC-compatible. If this product is improperly integrated into...

  • Page 16: Mechanical Connection Conditions

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Electrical installation 5.3.4 Mechanical connection conditions Rated motor current [A] Thread size Thread size Terminal board Cable glands up to 20 > 20 - 35 > 35 - 63 >...

  • Page 17: Temperature Monitoring

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Electrical installation 5.3.7 Temperature monitoring • The temperature monitoring by the PTC thermistor or temperature sensor (PT100) must be evaluated. • Only connect to the inputs suitable for the relevant monitoring type. •...

  • Page 18: Cable Length

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Electrical installation 5.4.1 Cable length • Maximum line length: 25 m • Connection and extension cable: Available as an option • Connection and extension cable version: Shielded twisted pair cable S64- S64- ECN1313...

  • Page 19: Absolute Encoder Ae-S64-Bissc-05-Za/Ae-S64-Bissc-10-Za

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Electrical installation 5.4.2.2 Absolute encoder AE-S64-BISSC-05-ZA/AE-S64-BISSC-10-ZA Jumper Function Designation D-SUB 15 pole DATA+ Data line for communication with the absolute encoder DATA- Data line inverse Voltage supply +5 V DC Power supply ground Analog track B (sine) CLOCK-...

  • Page 20: Absolute Encoder Ae-S64-Sincos-07-Ae

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Electrical installation 5.4.2.4 Absolute encoder AE-S64-SinCos-07-AE Wire-end sleeves Function Designation Grey Commutation signal (cosine) Pink Commutation signal inverse (inverse cosine) black Commutation signal (sine) Brown Voltage supply +5 V DC White Power supply ground Blue...

  • Page 21: Electromechanical Contactors

    Bridge rectifier* Table 5-5-4-2 * Bridge rectifier is not included in the scope of supply, ZIEHL-ABEGG SE it is available as option from as item 00154988 To reduce noises during brake disconnect the brakes should be switched to the alternating current side (K4), while normal operation.

  • Page 22: Connection Diagram

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Electrical installation 5.5.6 Connection diagram Brake wiring diagram with micro switch Figure 5-5-6-01 (1) Brake release monitoring (2) Brake (3) Shown with currentless brake Brake wiring diagram with inductive proximity switch Figure 5-5-6-02 (1) Brake release monitoring (2) Brake...

  • Page 23: Connection Diagram

    Be aware of the protection class specified on the name plate. " " Do not operate the elevator machine in an explosive atmosphere. " " For all usage conditions that differ from the order, please contact ZIEHL-ABEGG SE. First Start-up Observe the following points before the initial start-up: " "...

  • Page 24: Testing The Brake In Accordance With En 81-20:2020

    The logic of the principle circuit diagram should be understood. Transferability to the relevant application must be verified and ZIEHL-ABEGG SE provides no guarantee of suitability. If the circuit is designed in accordance with the principle circuit diagram: "...

  • Page 25: Emergency Evacuation

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Commissioning Note Note that an overload in the car leads to an increase in the motor torque. 25 % overload results in 150 % of the required motor torque! As regulated elevator machines are normally designed for a maximum torque of ca.

  • Page 26: Releasing The Brake With Electric Emergency Power Supply (Ups)

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Commissioning Danger! Operate the levers for hand release carefully. Operating the lever for hand release starts movement of the loads. Brake type RTW 1000 approx. 200 N Release force per brake circuit Table 6-5-2-1 Information Carefully operate the lever for hand release until the traction sheave or the car starts to move.

  • Page 27: Faults And Remedy

    (and transformer) Incorrect/faulty brake actuation Check brake actuation Brake coil defective Replace brake (special tool required. ZIEHL-ABEGG SE Contact customer serv- ice). Brake worn out Replace the brake rotors (Special tool re- quired! Contact the customer service of ZIEHL-ABEGG SE).

  • Page 28: Service And Maintenance

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Service and maintenance 8 Service and maintenance General notes on maintenance " " Observe the safety-at-work regulations! " " Disassembly of the elevator machine is not permissible. " " Never use a high-pressure cleaner (for example steam jet cleaner) for cleaning the elevator machine! "...

  • Page 29: Checking The Air Gap

    Spare parts Spare parts and accessories not supplied by ZIEHL-ABEGG SE have not been tested or approved by us. These parts may be lower in function or quality and there fore can reduce functionality or safety of the elevator machine installation.

  • Page 30: Replace The Absolute Encoder

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Service and maintenance Available spare parts: 1. Absolute encoder 2. Complete brake 2.1 Brake rotors with O-rings 2.2 Micro switch for brake 2.3 Inductive proximity switch for brake 3. Traction sheave 4.

  • Page 31: Required Tool For The Replacement Of The Brake

    Brake design ZAtop SM210.60B/SM210.70B Brake design ZAtop SM210.60/SM210.70 8.3.2.1 Required tool for the replacement of the brake: • ZIEHL-ABEGG tool set article 70030741 • Tool for replacing the absolute encoder (see chapter "Replacement of the absolute encoder") • Wire cutter •...
  • Page 32 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Service and maintenance 5. Feed all connecting cables (5) out of the terminal box. 6. Remove the cable ties at the brake cables. 7. Remove the cable from the fixing plate (6). 8.
  • Page 33 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Service and maintenance 11. Screw the assembly shaft (11) with tightening torque using the allen wrench SW 17 onto the motor shaft. Tightening torque: 60 Nm 12. Caution!Due to the great weight of the brake body, we recommend you to secure and change the brake body by using an eye bolt M12 (A ) and appropriate lifting gear.

  • Page 34: Mounting The Brake

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Service and maintenance 8.3.2.3 Mounting the brake Scope of delivery for the brake and assembly kit (article 70029992) in case of replacement delivery Designation Pos. Count Varistor Hexagon head screw M16 x 150 - 8.8 with washer Brake body Brake rotor O-ring...
  • Page 35 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Service and maintenance 1. Ensure that the friction disc of the brake rotor (14), the braking surface (B) of the flange bearing bracket and the toothed motor shaft (15) of the motor are free of dirt and grease. Perform cleaning with a micro-active cloth and quick cleaner LOCTITE®...
  • Page 36 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Service and maintenance 11. Release assembly shaft (11) loosen with an allen wrench SW 17 and take it off the motor shaft. 12. Provide threadlocker Loctite 243 or a similar product to the thread of the adapter shaft (9). 13.

  • Page 37: Functional Test On Microswitch/Inductive Proximity Switch For Release Monitor

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Service and maintenance 16. Screw on the fixing plate (6) with both hexagon head screws M8 x 16 - 8.8 (7) using a screw wrench SW 13 Tightening torque: 23 Nm 17.

  • Page 38: Replacement Of The Traction Sheave

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Service and maintenance 8.3.3 Replacement of the traction sheave The replacement of the traction sheave is described in separate assembly instructions: Replacement of the traction sheave see A-TIA19_02-D/A-TIA19_02-GB 8.3.4 Replacement of the bearing bracket The mounting and dismounting of the magnet rotor and the flange bearing bracket must only be carried out by qualified personnel and with special devices in the factory.

  • Page 39: Mounting Of The Thermostatic Switch

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Service and maintenance Parts list: Designation Pos. Count pre-assembled forced ventilation Hexagon head screw ISO 4017 - M12 x 20 - 8.8 thermostatic switch included insulating tube cable tie The accessories pos.

  • Page 40: Enclosure

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure 1 Thermal contact 5. On-site connection must be made by the customer according to the wiring diagram in the separate terminal box of the external ventilation. 9 Enclosure Technical data 9.1.1 motor...

  • Page 41: Protection Rating

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure 9.1.3 Protection rating Component Protection rating motor IP 42 Absolute encoder IP 40 Brake (electrical) IP 54 Brake (mechanical) IP 10 Complete machine IP 21 9.1.4 Ambient conditions The user must ensure that the specified ambient conditions are observed.

  • Page 42: Dimensions

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure Dimensions 9.2.1 Dimension sheet ZAtop SM210.60B/SM210.70B A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 42/96...
  • Page 43 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure 9.2.2 Legend for dimension sheets 1 Number of grooves represented schematically 2 Encoder 3 Motor connection possible on both sides 1 x maximum Ø 40 1 x Ø 16 with cable gland M16 4 Brake connection 5 Rope guard 6 Optional 3rd rope retainer...

  • Page 44: Ec/Eu Declaration Of Conformity

    Enclosure EC/EU declaration of conformity - Translation - (english) A-KON16_02-GB 2021/31 Index 003 Manufacturer: ZIEHL-ABEGG SE Heinz-Ziehl-Straße 74653 Künzelsau Germany The manufacturer shall bear sole responsibility for issuing this EC/EU declaration of conformity. Product description: ZAtop Gearless elevator machine Type: SM132...
  • Page 45 The authorised representative for the assembly of the technical file is: Mr. Roland Hoppenstedt (see above for address). Künzelsau, 03.08.2021 (Location, date of issue) ZIEHL-ABEGG SE ZIEHL-ABEGG SE Werner Bundscherer Roland Hoppenstedt Director Drive Division Technical Director Drive Technology...

  • Page 46: Declaration Of Conformity

    Enclosure UK Declaration of conformity - Original - (english) A-KON16_02-GB-UK 2022/31 Index 001 Manufacturer ZIEHL-ABEGG SE Heinz-Ziehl-Straße 74653 Künzelsau Germany This declaration of conformity is issued under the sole responsibility of the manufacturer. Product description ZAtop Gearless elevator machine Type SM132...
  • Page 47 The person authorised to compile the technical file is: Mr. André Lagies (see above for address). Künzelsau, 05.08.2022 (place and date of issue) ZIEHL-ABEGG SE ZIEHL-ABEGG SE Roland Hoppenstedt André Lagies Technical Director Drive Technology Head of R&D Machines Drive Technology...

  • Page 48: Operating Instructions Brake

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure Operating instructions brake A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 48/96...
  • Page 49 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 49/96...
  • Page 50 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 50/96...
  • Page 51 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 51/96...
  • Page 52 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 52/96...
  • Page 53 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 53/96...
  • Page 54 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 54/96...
  • Page 55 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 55/96...
  • Page 56 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 56/96...
  • Page 57 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 57/96...
  • Page 58 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 58/96...
  • Page 59 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 59/96...
  • Page 60 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 60/96...
  • Page 61 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 61/96...
  • Page 62 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 62/96...
  • Page 63 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 63/96...
  • Page 64 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 64/96...
  • Page 65 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 65/96...

  • Page 66: Assembly And Adjustment Of The Release Monitor With Microswitch

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure 9.5.1 Assembly and adjustment of the release monitor with microswitch A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 66/96...
  • Page 67 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 67/96...

  • Page 68: Assembly And Adjustment Of The Release Monitor With Inductive Proximity Switch

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure 9.5.2 Assembly and adjustment of the release monitor with inductive proximity switch A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 68/96...
  • Page 69 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 69/96...
  • Page 70 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 70/96...
  • Page 71 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 71/96...

  • Page 72: Eu Declaration Of Conformity For Brake

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure EU Declaration of Conformity for Brake A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 72/96...

  • Page 73: Ukca-Declaration Of Conformity For Brake

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure UKCA-Declaration of Conformity for Brake A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 73/96...

  • Page 74: Eu Type Examination Certificate

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure EU Type Examination Certificate A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 74/96...
  • Page 75 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 75/96...
  • Page 76 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 76/96...
  • Page 77 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 77/96...
  • Page 78 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 78/96...
  • Page 79 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 79/96...

  • Page 80: Statement On Type Examination Certificates

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure 9.8.1 Statement on type examination certificates The rated brake torques can be found on the name plate. The switching times are assigned to the brake torque in the type examination certificate. Increases in the index (added with “/”) for a type examination certificate are only used for technical improvements and are approved by the authorised body with this condition.

  • Page 81: Type Examination Certificate

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure UK Type Examination Certificate A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 81/96...
  • Page 82 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 82/96...
  • Page 83 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 83/96...
  • Page 84 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 84/96...
  • Page 85 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 85/96...
  • Page 86 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 86/96...

  • Page 87: Calculation Of Tripping Speed

    Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure 9.10 Calculation of tripping speed = diameter of the traction sheave (table contains typical traction sheave diameters, other diameters can be recalculated linear) = maximum nominal speed of the brake rotor Nbmax = maximum trip torque of the brake rotor = maximum rated speed of the elevator...

  • Page 88: Calculation Proof

    ZAtop – model series SM210.60B/SM210.70B Enclosure Calculation proof 9.11 - Original - (english) A-BN17_06-GB 2022/47 Index 003 Manufacturer: ZIEHL-ABEGG SE Heinz-Ziehl-Straße 74653 Künzelsau Germany Confirmation concerning the examination of traction sheave shaft calculation including shaft- hub-connections. Type of the gearless ZAtop SM210.60B maschine:...
  • Page 89 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure Construction drawing: A-21-121-0006_02 index A03 dated 04.04.2017 A-21-121-0006_02 index A04 dated 19.12.2019 Permissible shaft ma- Steel DIN EN 10083-3:2007-01 – 42CrMo4+QT (1.7225+QT) terials: Steel DIN EN 10083-3:2007-01 – 42CrMo4+QT (1.7227+QT) Steel DIN EN 10083-3:2007-01 –...
  • Page 90 It should be noted that on the brake side only braking torque is applicable, because the calculation does not take into account the additional transverse forces due to the braking effect on the traction sheave shaft. Künzelsau, 25.11.2022 (Location, date of issue) ZIEHL-ABEGG SE ZIEHL-ABEGG SE Roland Hoppenstedt André Lagies Technical Director Drive Technology Head of R&D Machines Drive Technology...

  • Page 91: Calculation Proof

    ZAtop – model series SM210.60B/SM210.70B Enclosure Calculation proof 9.12 - Original - (english) A-BN17_07-GB 2022/47 Index 003 Manufacturer: ZIEHL-ABEGG SE Heinz-Ziehl-Straße 74653 Künzelsau Germany Confirmation concerning the examination of traction sheave shaft calculation including shaft- hub-connections. Type of the gearless ZAtop SM210.70B maschine:...
  • Page 92 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure Construction drawing: A-21-121-0006_03 index A03 dated 04.04.2017 A-21-121-0006_03 index A04 dated 19.12.2019 Permissible shaft ma- Steel DIN EN 10083-3:2007-01 – 42CrMo4+QT (1.7225+QT) terials: Steel DIN EN 10083-3:2007-01 – 42CrMo4+QT (1.7227+QT) Steel DIN EN 10083-3:2007-01 –...
  • Page 93 It should be noted that on the brake side only braking torque is applicable, because the calculation does not take into account the additional transverse forces due to the braking effect on the traction sheave shaft. Künzelsau, 25.11.2022 (Location, date of issue) ZIEHL-ABEGG SE ZIEHL-ABEGG SE Roland Hoppenstedt André Lagies Technical Director Drive Technology Head of R&D Machines Drive Technology...
  • Page 94 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 94/96...
  • Page 95 Translation of the original operating instructions ZAtop – model series SM210.60B/SM210.70B Enclosure A-TBA17_01-GB 2023/46 Index 008Part.-No. 01013389-GB (EU-BD 1014/1) 95/96...
  • Page 96 Customer Service phone +49 7940 16-308 +49 7940 16-249 drives-service@ziehl-abegg.com Headquarters ZIEHL-ABEGG SE Heinz-Ziehl-Straße · 74653 Künzelsau Germany phone +49 7940 16-0 · fax +49 7940 16-249 drives@ziehl-abegg.de · www.ziehl-abegg.com...
