INSTALLATION MANUAL
DROP-ARM AWNING V124 - CALPE

Advertisement

loading
Need help?

Need help?

Do you have a question about the Calpe V124 and is the answer not in the manual?

Questions and answers

Related Manuals for Verano Calpe V124

Summary of Contents for Verano Calpe V124

  • Page 1 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE...

  • Page 2: Necessary Tools

    INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE Content 1. Drop-arm awning * 2. Wall supports 3. Control a. Manual control: crank handle b. Electrical control: switch and plug c. Remote control: remote control and plug * The pictured awning is provided with manual control. Necessary tools •...
  • Page 3 General warning Installation of the Verano® product yourself is at your own risk. Only use this instruction as a tool and for the installation of this specific Verano® product. If you cannot install the product yourself, you can always opt for professional installation.
  • Page 4 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE Installation of the wall supports 1.1 Marking the holes The wall supports need to be installed 10 to 15 centimeter from the ends (figure 1.1). Optional remaining wall supports need to divided equally between the two outer wall supports. X = Width of the awning Wall support Wall support...
  • Page 5 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE 1.2 Drilling the holes Drill the installation holes. Use matching plugs and bolts of high quality. Install the wall supports (A) and tighten the bolts. See figure 1.3. Figure 1.3 Installation of the wall support. 1.3 Drilling the hole for control 1.
  • Page 6 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE Installation of the awning 2.1 Placing the awning (manual control outside) Hang the awning in the wall supports. See figure 2.1 and 2.2. Proceed with step 2.3 “Securing the awning”. Figure 2.1 Hanging the awning (control outside). Figure 2.2 Detail wall support.
  • Page 7 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE 2.2 Placing the awning (control inside) 1. Hang the awning in the wall supports. See figure 2.3 for electrical control or 2.4 for tape control. 2. Cable: slide the electrical cable inside through the drilled throughput. Tape: install the tape guide with the opening over the throughput and the pulley on top.
  • Page 8 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE 2.3 Securing the awning 1. Lock the wall supports using the included locking bolts. The locking bolts need to be placed manually. If this fails, the wall supports are not aligned correctly! 2. Fixate the locking bolts by turning them a quarter turn (anticlockwise if you are standing beneath the awning). Fixate the locking bolt with the included nut.
  • Page 9 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE Installation drop-arms 3.1 Drilling the holes for the lower arm support Drill the holes following the drawing below. The pictured sizes are the minimal sizes for the drilled hole to be from the side of the awning.
  • Page 10 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE 3.3 Fixating the arms to the front bar Turn the drop-arm up and stick it in the front bar. Lock the drop-arm by turning the screw on the front side (figure 3.6). Figure 3.6 Placing the locking bolts. 3.4 Adjusting the front bar Make sure that the front bar is 15 mm from the top cap over the whole width (figure 3.7).
  • Page 11 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE Instruction for placing the strap coiler (outside) 1. Determine the position of the strap guide (50 mm to 100 mm below the boxing of the drop-arm awning) and mark both holes on the window frame or the wall.
  • Page 12 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE 9. Put the end of the pull strap through the strap coiler and place the hole over the flap to make sure that it is fixated well. Attention! You may never prematurely shorten the strap! You need the length of the strap when you open the drop-arm awning.
  • Page 13 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE Instruction placing the strap coiler (inside) 1. Put the pull strap through the guide wheel on the inside. Make sure that the pull strap is not twisted. 2. Place the guide wheel in the control hole. 3.
  • Page 14 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE 7. Put the end of the pull strap through the strap coiler and place the hole over the flap to make sure that it is fixated well. Attention! You may never prematurely shorten the strap! You need the length of the strap when you open the drop-arm awning.
  • Page 15 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE Instruction for placing the electrical control (inside) 1. Determine the position of the switch on the inside and mark both holes on the wall. 2. Drill the holes with a 6 mm drill. Ø6 230 V 3.
  • Page 16 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE 5. Connect the 4-wired cable of the motor and the 3-wired cable and plug following the scheme below. Turn to an installer if necessary. Motor left (seen from the outside) Motor right (seen from the outside) 6.
  • Page 17 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE Fixation of the drop-arm support Open the awning to make sure that you have access to the upper hole of the drop-arm support. Drill the fixation hole through the free hole in the bracket. Attention! Make sure that drill cuttings do not fall in the hinge of the drop-arm. The cuttings can obstruct the functioning of the hinge.
  • Page 18 INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE Valance 8.1 Place the valance To place the valance, follow the steps below. See figure 8.1. 1. Remove the cap from the front bar on one side. The fabric tendon is locket in the front bar. 2.

  • Page 19: User Information

    INSTALLATION MANUAL DROP-ARM AWNING V124 - CALPE User information A high quality cloth is integrated into your chosen screen. In view of optimal quality we have chosen a high technology production process in which every step of the production is strictly selected. By way of automation, permanent checks, laboratory tests and finely detailed after-care, nothing is left to chance.
