- Page 1 Installation manual Drop-arm awning V160 Florence...
-
Page 3: Necessary Tools
Installation manual drop-arm awning V160 Florence Content 1. Drop-arm awning * 2. Control a. Manual control: crank handle b. Manual control: manual control mono inside ( winding machine inside + crank handle) c. Electrical control: switch + plug d. Remote control:... - Page 4 Important before installation General warning Installing the Verano® product yourself is at your own risk. Only use this instruction as a tool and for the installation of this specific Verano® product. If you cannot install the product yourself, you can always opt for professional installation. The installation team of Verano®...
- Page 5 Installation manual drop-arm awning V160 Florence Installation of the wall supports 1.1 Marking the holes for the wall supports The wall supports need to be installed 10 cm to 15 cm from the ends (fig 1.1). Optional remaining wall supports need to be divided equally between the two outer wall supports.
- Page 6 1.2 Drilling the holes Drill the installation holes. Use matching, high quality plugs and bolts (standard A2 or for a sea climate A4). Install the awning to the wall and fixate the bolts. See figure 1.3. fig. 1.3 Installation of the wall support 1.3 Drilling the operating hole (when operating indoors) 1.
- Page 7 Installation manual drop-arm awning V160 Florence 1.6 Extra wall supports with a weak wall If there are less than 5 stones above the installation location, an extra wall support is needed. This extra wall support divides the power over a bigger wall surface, this way the wall can carry more weight. See figure 1.6.
- Page 8 2.2 Installation of the awning with inside control 1. Hang the awning in the wall supports. See figure 2.3 or electrical control or 2.4 for manual control mono inside. 2. Cable: lead the electrical cable inside through the drill lead-through hole. Cable snoer mono commando...
- Page 9 Installation manual drop-arm awning V160 Florence 2.3 Securing of the awning 1. Secure the wall supports using the included bolts. The bolts need to be applied manually. If this is not possible, the wall supports are nog aligned well! Attention! The awning may not be opened before the securing bolts are in place! fig.
- Page 10 Installation of the drop-arms 3.1 Marking the holes for the drop-arms Mark the drop-arms following the drawing below. The drop-arms need to be placed in one line. If the positions of the drop-arms are not levelled, the awning will not function well. The pictured sizes are the minimal sizes that the drop-arm needs to fall inside the drop-arm awning.
- Page 11 Installation manual drop-arm awning V160 Florence 3.3 Setting the sheets to the arms Slide the sheets in the ends of the arms. Make sure that the sheets are faced downwards (fig. 3.5). Fixate the sheets with the included screws (fig. 3.6) fig.
- Page 12 Installation instructions manual mono operation (inside) 1. Determine the length of the square axle and cut it to size. 2. Slide the axle through the wall into the windings of the drop-arm awning. 3. Position the knee joint and mark the drill holes on the frame or wall.
- Page 13 Installation manual drop-arm awning V160 Florence Installation of electrical control (inside) 1. Determine the position of the switch and mark two holes on the inside of the wall. 2. Drill the holes with a 6 mm drill. Ø6 230 V 3.
- Page 14 5. Connect the 4-wired cable of the motor and the 3-wired cable and plug following the scheme below. If necessary, ask an installer for advise. Motor left (seen from the outside) Motor right (seen from the outside) 6. Install the switch. When a wireless remote control is used, the 3-wired cable can be connected directly to the socket.
- Page 15 Installation manual drop-arm awning V160 Florence Setting of the front bar Make sure that the front bar is located at an equal distance from the cap over the whole width (fig. 6.1). Set the front bar by loosening the bolts of the drop-arm in one turn (fig 6.2). After that, the drop-arm can slide up and down (fig. 6.3). If the front bar is set well, you can fix the bolts of the drop-arm (fig 6.4).
-
Page 16: User Information
User information A high quality cloth is integrated into your chosen in your screen that are difficult to detect and impossible screen. In view of optimal quality we have chosen a high to avoid. They are inherent in all technical materials but technology production process in which every step of do not reduce the technical presentation and durability the production is strictly selected. - Page 17 Installation manual drop-arm awning V160 Florence Notes V 16 0- 13 22 76 48 -1 8 0 8 3 0 E N(2 )
- Page 18 www.verano.eu...
