- Page 1 Installation manual Conservatory awning V610 Oslo...
-
Page 2: Necessary Tools
Important before installation General warning Installing the Verano® product yourself is at your own risk. Only use this instruction as a tool and for the installation of this specific Verano® product. If you cannot install the product yourself, you can always opt for professional installation. The installation team of Verano® is pleased to help you. Be careful for damages Don’t use a knife or any other sharp object when opening the packing. - Page 3 Installation manual V610 Oslo Sizes in mm Awning length Total awning width Awning length Total awning width Awning width Awning width High foot High foot Foot Intermediate roll Foot Intermediate roll Fig. 1 Side view 26,75 26,75 26,75 26,75 Fig. 2 Front view...
- Page 4 The cord (see Figure 7) • Open the cover of the conservatory awning. • Dismount the cover from the pull frame. • Loosen the cord at the cord fixation block and loosen the fixation screw. • Demount the covers of the rotary wheel blocks. • Block the connection between the left and right cord by sticking a screwdriver through the closure and pull frame. There is a hole in the pull frame intended for this purpose. Warning! There must be two strokes of cord Cord melter...
- Page 5 Installation manual V610 Oslo Optional: Linking the V610 Oslo (see Figure 8) A linked V610 Oslo has a coupling pin already mounted in the motor section. 1. Place the part with the motor. 2. Demount the coupling pin. Therefore remove the allen screws M6 (1) on the plug at the motor side and remove the strip (2).
- Page 6 • Close the box. • Close the pull frame. Remark At larger widths of the V610 Oslo the pull frame without a cover can sag, making it appear that the cover is too wide. To close the pull frame, you need to lift it slightly in the middle. Subject to misprints, errors and technical modifications.
-
Page 7: Manufacturer's Warranty
- Does not include the replacement of fuses, limit switches and slide contacts; - It is Verano®’s obligation to give to the buyer whatever right to compensation or dissolution of the purchase contract; - Verano® reserves its right, without previous notification, to carry out changes in its products;...
