Fullwood M2erlin Operating Instructions For Safe Use page 72

Ref / Pt.No: 294130
Revision: C
Date: 24-Mar-17
61 error BUCKET ERROR
62 error IDENTIFICATION
ERROR
63 error DATABASE
ERROR
64 error AIR PRESSURE
65 error LIGHTNING
PROTECTION
66 error NO COW
TIMEOUT
67 warning CRYSTALAB
_ERROR
68 error MILKPUMP
_INVERTER
294130
Operating Instructions for Safe Use
Fullwood M²erlin
Bucket system has problems
reaching Bucket or Park
position.
Multiple cows in crate not
identified in time.
Cow separation, maximum no.
of animals with unknown tags
reached.
Air pressure switch is disabled.
Lightning protection input is
disabled.
No cow being milked for longer
than 1 hour without Merlin being
off-line or in pause (Adjustable
in Crystal 2.7).
The crystalab has produced
errors which aren't expected
every milking, if this continues
every milking Crystalab is
probably broken.
The milk pump inverter is in
error and not working.
No Data No Data
Broken antenna / The system has been
broken ID circuit unable to identify X
board / wrong animals in a row.
configuration.
No Data No Data
An error will be The input activated by
generated, all the air pressure
activities will be monitoring unit is
stopped and Merlin deactivated.
will go into off-line
mode.
An error will be The input activated by
generated, all the air pressure
activities will be monitoring unit is
stopped and Merlin deactivated.
will go into off-line
mode.
An error will be No cow alarm setting
generated and Merlin has expired.
will go into pause
mode.
Info messages are The crystalab has
generated, System produced errors which
will continue milking. aren't expected every
milking, if this continues
every milking Crystalab
is probably broken.
An error will be The input activated by
generated, all the milk pump inverter is
activities will be deactivated.
stopped and Merlin
No Data
Verify/exchange antenna
(wiring) / verify / exchange
ID circuit board / verify
power supply to ID circuit
board.
No Data
Check air pressure and
reset alarm.
Check lightning protection
and reset alarm.
Check the system and
reset alarm.
Check CrystaLab.
Check milk pump inverter
and reset alarm.
Page 72 of 81
