Fullwood M2erlin Operating Instructions For Safe Use page 58

Ref / Pt.No: 294130
Revision: C
Date: 24-Mar-17
Crate
Check operation of gates
Change gate linkage bushes (Pre Rev 1.5)
Change gate linkage bushes (Rev 1.5)
Check and clean cow follower camera
Miscellaneous
Check E-stop functionality
Check Machine Stop
Check RCBO
Visually check earth connections
Check all covers are fitted correctly
Check any other equipment controlled by M²erlin (Bulk tank, Buffer
Tanks and Gates)
Visually check complete system watch milking
Fill in service record
Replace Tank Sampler Seal
Replace Sampler Tube
Cartesian
Change All Belts
Change all Rollers
Check revision of machine for correct 'End Gate Linkage Bushes' to be fitted during service one in year 2,
3, 4 ........
Change end gate linkage bushes (Pre
Rev 1.5)
Change end gate linkage bushes (Rev
1.5)
Subject to options fitted, chose the following to be fitted during service one in year 2, 3, 4 ........
Change acid injection periceltic pump
tube
Change CrystaLab Rubber connections
Change Crystalab to receiver milk tube
Teat roll wash line change
Parts recommended to be changed periodically:
•
Vacuum pump oil to be changed 4 times a year, more often in case of continuous use
(Busch pump only)
•
Ensure oil vane pump is topped up with oil - 092671 5ltr Vac Pump Gear Box Oil
Liners are to be changed after 2500 cow milkings
294130
Operating Instructions for Safe Use
Fullwood M²erlin
1 x 291421 Pre Rev 1.5 Tri Link Service Kit (one gate)
1 x 291420 Rev 1.5 Tri Link Service Kit (one gate)
1 x 079462 Acid inject pump tube
1 off 133721 Crystalab Rubber Connector
1 x 033471, Mlk Mtr/Mlk Ln Connecting Tube
10m 030312 - Sil Tube 12nb/20mt/21od (old)
10m 293661 PUN-H_12x2-NT Tubing (new)
x x x
x* x*
x* x*
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
– or –
x x
x x
x x
x x
x x
x x
x x
x x
x x
x x
x
x
x
x
