2.19 Power Supply Specifications

•
Fullwood Ltd does not carry out any mains wiring. It is the responsibility of the
customer to arrange for all mains wiring to be carried out by a competent contractor
qualified in accordance with national and/or local legislation. This also applies to any
mains electrical connections from switches of isolators to electrical equipment
supplied by Fullwood Ltd.
•
The power requirements will vary significantly, depending on the ancillary equipment
specified.
Supply
1ph
3ph
•
Power consumption for all other pieces of equipment e.g.: Air Compressor, Vacuum
pump, Boiler Etc. will need to be calculated and specified per site.
•
Earthing; It is the responsibility of the customer to ensure that all metal parts of the
installation are bonded to earth in accordance with local and national legislation.
•
M²erlin must be earthed according to local legislation.
•
Starting up M²erlin without proper earthing will render the warranty null and void.

2.20 Ambient Temperature

Min
Max

2.21 Compressed Air Requirements

Number of M
Note: Contact Fullwood for installations of over six M²erlins
Note: Specifications above are the requirements of the machine not of the compressor.
Most rotary compressors are 100% duty cycle so calculations are required. Most piston
compressors are 50% duty cycle so the compressor output needs to be double the
requirement detailed above.

2.22 Air Drying

•
The dryer must be rated to operate efficiently at the lowest typical temperature for
the country/area.
294130
Operating Instructions for Safe Use
Fullwood M²erlin
Supply Voltage
Volts
216-253
376-440
2°C
45°C
2
erlins
CFM (m
1
2
3
4
5
6
Minimum supply pressure
Maximum supply pressure
Max Current Power factor
cos f
Amps
25 >0.8
16 >0.8
3
/hr)
2 (3.4)
4 (6.8)
5 (8.5)
6 (10.2)
7 (11.9)
8 (13.6)
7 bar
11 bar
Earth Leakage
mA RCD
100
100
Stored Air
150L
150L
200L
200L
250L
250L
