Summary of Contents for Det-Tronics FlexSonic
- Page 1 Instructions FlexSonic ™ Acoustic Detector AC100 Sensor ATX10 Transmitter Rev: 12/19 95-8657...
-
Page 2: Table Of Contents
Table of Contents OVERVIEW....................3 FEATURES ....................3 BENEFITS ....................3 SPECIFICATIONS ................... 4 DESCRIPTION ..................5 AC100 ....................5 ATX10 ....................6 OPERATION .................... 8 Basic Mode ..................8 Profile Mode ..................9 Data Storage/Management ............... 9 IMPORTANT SAFETY NOTES ...............13 INSTALLATION ..................13 Sensor Termination Box ..............13 Grease/Lubrication ................14... -
Page 3: Overview
When AC100 Sensor combined with line of sight and/or point gas detectors, the additional layer of protection provided by the FlexSonic Acoustic Detector offers the ultimate solution for gas leak detection. FEATURES • Long range response •... -
Page 4: Specifications
–55°C to +75°C (–67°F to +167°F) Safety Reference Manual (form 95-8658) for details. Storage: –55°C to +85°C (–67°F to +185°F). ELECTRO-MAGNETIC COMPATIBILITY— HUMIDITY— EMC Directive 2014/30/EU 5 to 95% RH, non-condensing (Det-Tronics verified). Emissions: EN61000-6.3 INGRESS PROTECTION— EN61000-6.4 IP66, NEMA/Type 4X. Immunity: EN61000-6.1 EN61000-6.2... -
Page 5: Description
Figure 1—Dimensions of Acoustic Detector in Inches (Centimeters) DESCRIPTION ATX10 only CURRENT OUTPUT— The FlexSonic Acoustic Detector is comprised of two 4-20 mA with HART (non-isolated, sourcing*) main components: the AC100 Acoustic Sensor, and the 20 mA indicates Alarm condition ATX10 Acoustic Transmitter. -
Page 6: Atx10
ATX10 The main function of the ATX10 Transmitter is to evaluate TEST SWITCH the incoming acoustic power spectrum data from the AC100 Acoustic Sensor and make a determination of ALARM LED alarm condition. The transmitter communicates with the sensor via proprietary serial connection. FAULT LED TEST ALARM... - Page 7 ATX10 faceplate for at least 3 seconds. The the FlexSonic detector to exceed 60 minutes before Reset switch resets any alarms or faults and places the indicating a failed AIC. See table below: detector back in the normal operating mode.
-
Page 8: Operation
The following events are recorded to the ATX10 event log: BASIC MODE • Alarm The Basic Mode setting of the FlexSonic Acoustic • Clear Alarm Detector provides an adjustable, flat level alarm • Pre-Alarm threshold when the background acoustic environment •... -
Page 9: Profile Mode
1 second interval. When the Memory Module has reached capacity An important advantage is that the FlexSonic Acoustic of real time log information, it will overwrite the older files. Detector is immediately operational out-of-the-box while simultaneously performing an on-site sound Configuration Data Copy–... - Page 10 DOWNLOAD – This command modifies the ATX10 Figure 3 is a flow chart showing how the Memory flash memory by replacing all configuration and profile Module annunciations arise, and the user intervention data with the contents of the files on the SD Memory options that are available to get the Memory Module Module.
- Page 11 Prior to removal of the Memory Module/SD card, it is SD Memory Module Removal / Replacement recommended that the REMOVE option be selected The ATX10 Memory Module is a dual plug daughter via HART. This will disable communication to the SD board located on the back side of the ATX10 transmitter card and annunciate an advisory fault.
- Page 12 UNLOCK STEP #1 SLIDE THE LOCKING CONNECTOR BACK APPROXIMATELY 1/8 INCH (3 MM) TO UNLOCK THE SD CARD. STEP #2 WHEN UNLOCKED, THE CARD/CONNECTOR ASSEMBLY AUTOMATICALLY OPENS TO THIS POSITION. STEP #3 MOVE THE CARD/CONNECTOR ASSEMBLY TO THIS “FULL OPEN” POSITION.
-
Page 13: Important Safety Notes
Device repair should be performed only by the manufacturer. SENSOR TERMINATION BOX A Det-Tronics sensor termination box (Model STB) LIABILITIES The manufacturer’s warranty for this product is is required for installations where the AC100 is not connected directly to the ATX10 transmitter housing. -
Page 14: Grease/Lubrication
Conduit drains must be installed at water collection points to automatically drain accumulated moisture. It is not required to aim the FlexSonic detector toward Conduit breathers should be installed at upper locations a potential leak source. The preferred orientation for to provide ventilation and allow water vapor to escape. -
Page 15: Detector Coverage
A2611 rate, environment, and installation factors described. Reference detection ranges for the FlexSonic Acoustic Coverage Range of FlexSonic Acoustic Detector (Low Level Leak) Detector are provided below (detector mounted 2 meters above ground pointing vertically downwards, and low ambient background noise > 20 kHz):... -
Page 16: Power Supply Requirements
POWER SUPPLY REQUIREMENTS CAUTION The use of proper conduit installation techniques, Calculate the total gas detection system power breathers, glands, and seals is required to prevent consumption rate in watts from cold start-up. Select a water ingress and/or maintain the explosion-proof power supply with adequate capability for the calculated rating. - Page 17 ORIENT SET SCREW AWAY FROM MOUNTING SURFACE TO ENSURE ADEQUATE CLEARANCE BETWEEN SENSOR AND SURFACE A2618 Figure 8—AC100 Connected to Termination Box (M25 Model Shown) M25 Models 4. Tighten the lock nut against the termination box. See Figure 10. M25 models have straight threads and a removable connector assembly with lock nut.
-
Page 18: Wiring Procedure
TIGHTEN LOCK NUT AGAINST TERMINATION BOX TIGHTEN WITH 35MM SOCKET WRENCH A2620 Figure 10—Connector Assembly Attached to Termination Box Figure 15 shows power and signal wiring for an ATX100 WIRING PROCEDURE wired to a PLC. Ensure that all cables are terminated properly. Conductor insulation should be stripped off with a bare Figure 16 shows an ATX10 with AC100 wired to a FlexVu conductor length of 0.2 inch (5 mm) minimum and 0.7... - Page 19 INTERFACE TO SOFTWARE CONFIGURATOR SENSOR POWER AND 4-20 mA OUTPUT A2605 Figure 12—ATX10 Transmitter Wiring Terminals ATX10 TRANSMITTER INTERFACE BOARD TO SOFTWARE CONFIGURATOR ORANGE GRAY BLACK SENSOR POWER GREEN AND OUTPUT IS GROUND NOTES: DEVICE HOUSINGS MUST BE ELECTRICALLY CONNECTED TO EARTH GROUND. AC100 ACOUSTIC CONNECT THE GREEN WIRE FROM THE AC100 TO THE GROUND SCREW...
- Page 20 ATX10 TRANSMITTER INTERFACE BOARD TO SOFTWARE CONFIGURATOR STB TERMINATION BOX IS GROUND ORANGE GRAY SENSOR POWER AND OUTPUT GREEN NOTES: DEVICE HOUSINGS MUST BE ELECTRICALLY CONNECTED TO EARTH GROUND. CONNECT THE GREEN WIRE FROM THE AC100 TO THE GROUND SCREW INSIDE THE STB HOUSING.
- Page 21 ATX10 TRANSMITTER INTERFACE BOARD TO SOFTWARE CONFIGURATOR PLC 4-20 mA INPUT CARD INPUT 4-20 mA – 24 VDC OHMS MINIMUM SENSOR POWER AND OUTPUT Notes: Resistor may be external if voltage input card is used. A2608 Sinking resistance at PLC must be 250 ohms minimum for HART communication.
- Page 22 ATX10 TRANSMITTER 250 OHMS 24 VDC – IS GROUND AC100 ACOUSTIC HART SENSOR HANDHELD A2617 COMMUNICATOR Figure 17—Wiring the Acoustic Detector for Benchtop Testing/Programming Using HART Protocol 95-8657...
-
Page 23: Startup
MODE BASIC/ BASIC MODE NOTE SD MENU PROFILE/ LEVEL (dB) SET RTC Upon powering up the Flexsonic, the ATX10 will ADVANCED DELAY (SEC) CALIBRATION MENU LATCHING annunciate a fault. This is due to the ATX10 trying AUTO LEVEL WRITE PROTECT BASIC MODE to establish communication with the SD card. - Page 24 Profile-Learn PROFILE MODE The Profile-Learn mode uses variable thresholds. Each ALARM MODE LEVEL/LEARN DEVICE SETUP ALARM SETUP LEVEL (dB) frequency band has its own threshold level, rather than ALARM SETUP MODE BASIC/ SENSITIVITY (dB) SD MENU PROFILE/ a fixed level that is applied to all bands. BAND COUNT SET RTC ADVANCED...
-
Page 25: Prealarm Configuration
5. Once the RECORDED data represents the desired PREALARM CONFIGURATION profile, navigate to the SAVED PROFILE menu. The PREALARM option is available in Profile-Level/Learn The SAVED PROFILE menu provides a preview of mode (not Basic), and can be configured as follows several slots for permanently storing the RECORDED through the PROFILE MODE menu. -
Page 26: Password Protection
• Rotating machinery / gear meshes • Bearings/fans motors • Metal-to-metal contact / chains • High velocity wind through rigging The FlexSonic Acoustic Detector can be effectively employed record acoustic background environment unique to an installation and provide a clear display of the information using the Acoustic Inspector software package. -
Page 27: Maintenance
To clean the AC100 Acoustic Sensor cover, ensure that NOTE the device is powered off, then simply grasp the cover Refer to the FlexSonic Acoustic Detector Safety assembly and twist counterclockwise. See Figure 18. Manual 95-8658 for specific requirements and... -
Page 28: Troubleshooting
Description Corrective Action AIC has failed. Microphone or emitter is AI FAULT Provide data log information to Det-Tronics for analysis. degraded. SD card is out-of-sync with the ATX10 on-board flash. It SD Memory Module has an issue will be necessary to either UPLOAD the data to the SD... -
Page 29: Device Repair And Return
STB7S5YW M25 Sensor Termination Box, (Stainless Steel model only) NOTE 226365-604 STB7S5NW 3/4 NPT Sensor Termination Det-Tronics reserves the right to apply a service Box, (Stainless Steel model only) charge for repairing returned product damaged as a result of improper packaging. 012402-001... - Page 30 ™ FlexSonic AC100 Acoustic Sensor Model Matrix MODEL DESCRIPTION AC100 Acoustic sensor TYPE MATERIAL Stainless Steel TYPE THREAD TYPE 3/4” NPT TYPE APPROVALS SIL/FM/CSA/ATEX/CE/IECEx TYPE CLASSIFICATION Division/Zone Ex d ™ FlexSonic ATX10 Transmitter Model Matrix MODEL DESCRIPTION ATX10 Transmitter for AC100...
-
Page 31: Appendix A - Fm Approval Description
APPENDIX A FM APPROVAL DESCRIPTION AC100 ATX10 Class I, Div1, Groups B, C & D Class I, Div1, Groups B, C & D Class II/III, Div1/Div2, Groups E, F & G Class II/III, Div1/Div2, Groups E, F & G Class I, Div2, Groups A, B, C & D Temperature code T5 Temperature code T4 Class I, Div2, Groups A, B, C &... -
Page 32: Appendix B - Csa Certification Description
APPENDIX B CSA CERTIFICATION DESCRIPTION AC100 ATX10 Class I, Div1, Groups B, C & D Class I, Div1, Groups B, C & D Class II/III, Div1/Div2, Groups E, F & G Class II/III, Div1/Div2, Groups E, F & G Class I, Div2, Groups A, B, C & D Temperature code T5 Temperature code T4 Class I, Div2, Groups A, B, C &... -
Page 33: Appendix C - Atex Approval Description
APPENDIX C ATEX APPROVAL DESCRIPTION AC100 ATX10 DEMKO 12 ATEX 1263479X DEMKO 12 ATEX 1263925X II 2 G II 2 G 0539 0539 ® II 2 D ® II 2 D APPROVED APPROVED Ex db ib IIC T4 Gb Ex db IIC T6 Gb Ex tb IIIC T80°C Db Ex tb IIIC T80°C Db T amb: –55°C to +75°C... -
Page 34: Appendix D - Iecex Approval Description
APPENDIX D IECEx APPROVAL DESCRIPTION AC100 ATX10 IECEx ULD13.0002X IECEx ULD13.0003X Ex db ib IIC T4 Gb Ex db IIC T6 Gb Ex tb IIIC T80°C Db Ex tb IIIC T80°C Db T amb: –55°C to +75°C T amb: –55°C to +75°C IP66 IP66 IEC Standards:... -
Page 35: Appendix E - Maritime Approval
APPENDIX E MARITIME APPROVAL DNV GL Type Approval Certificate No. TAA000017F. Subject Matter of the Approval Model AC100 Acoustic Sensor, ATX10 Transmitter, and STB Termination Box are found to comply with Det Norske Veritas’ Rules for Classification of Ships and Det Norske Veritas’ Offshore Standards. Application/Limitation Location Classes MODEL... -
Page 36: Appendix F - Additional Approvals
APPENDIX F ADDITIONAL APPROVALS RUSSIA & KAZAKHSTAN VNIIFTRI CERTIFICATE OF CONFORMITY TO “TP TC 012/2011” Sensor AC100 TC RU C-US. BH02.B.00277 1Exd[ib]IICT4 IP66 T4 (Tamb = –55°C to +75°C) Transmitter ATX10 TC RU C-US. BH02.B.00257 1ExdIICT6 IP66 T4 (Tamb = –55°C to +75°C) DECLARATION OF CONFORMITY TO “TP TC 020/2011 EMC”... -
Page 37: Appendix G - Approved Adjoining Assemblies
APPENDIX G APPROVED ADJOINING ASSEMBLIES DIRECT CONNECTION AC100 with ATX10 Maximum Separation Distance 500 Feet REMOTE SENSOR ATX10 AC100 with STB WITH UNIVERSAL DISPLAY FlexVu Model UD10 AC100 with ATX10 WARNING The AC100 must be connected as shown above for compliance with hazardous (classified) location requirements. - Page 38 Specifications subject to change without notice. All trademarks are the property of their respective owners. © 2020 Detector Electronics Corporation. All rights reserved. Det-Tronics manufacturing system is certified to ISO 9001— Corporate Office Phone: +1 952.941.6665 the world’s most recognized quality management standard.
