DESCRIPTION
The EQ2200UVHT UV Flame Detector is used with the
Eagle Quantum system to provide UV flame protection
in continuous duty high temperature applications,
such as turbine compartments, enclosures, generator
rooms, etc. where ambient temperatures can continu-
ously exceed +75°C (+167°F).
The EQ2200UVHT is an electronic module assembly
that is used in conjunction with a high temperature
rated C7050B UV detector (with DE1888K3 high tem-
perature rated UV sensor tube). The two devices are
mounted in separate explosion-proof, watertight
enclosures.
The UV detector is rated for continuous duty in envi-
ronments up to +125°C (+257°F). The electronic mod-
ule is rated up to +75°C (+167°F).
The electronic module cannot be located in the
high temperature area.
The UV detector and electronic module assembly can
be separated up to 165 feet (50 meters) using high
temperature rated 4 core shielded cable.
In accordance with NFPA 72, the maximum sep-
aration distance is 20 feet (6 meters) using con-
duit or equivalent protection against mechanical
damage.
*
o i
is Detector Electronics' Trademark for its patented Optical
Integrity Systems, U.S. Patent 3,952,196, United Kingdom Patent
1,534,969, Canada Patent 1,059,598.
©Detector Electronics Corporation 2001
®
NOTE
NOTE
SPECIFICATION DATA
Eagle Quantum
For Use With C7050B
Continuous Duty High Temperature
The detector is equipped with both automatic and
manual optical integrity (o i ) test capability.
LED
Detector status is indicated by a red LED that is visible
through the viewing window on the cover of the elec-
tronic module junction box. Table 1 indicates the con-
dition of the LED for each detector status.
OUTPUT
The output of the device is a status message that is
sent to the gateway and logic controller in the Local
Control Unit along the communication loop. System
response to the message is determined at the time of
configuration.
The device supports ANSI/NFPA 72
Class A, Style 7 communication with the LCU.
9/01
EQ2200UVHT
UV Flame Detector
90-1140
