Table A-13: Polled I/O Connection Instance 2
Attribute
ID
1
2
3
4
5
6
7
8
9
12
13
14
15
16
Table A-14: Common Services
Service
Code
0x05
0x0E
0x10
Pub. No. MN05003005E
Access rule Name
Get State
Get InstanceType
Get TransportClassTrigger
Get ProducedConnectionId
Get ConsumedConnectionId
Get InitialCommCharacteristics
Get ProducedConnectionSize
Get ConsumedConnectionSize
Get/Set ExpectedPackedRate
Get/Set WatchdogTimeoutAction
Produced Connection
Get
Path Length
Produced Connection
Get
Path
Consumed Connection
Get
Path Length
Consumed Connection
Get
Path
Implemented for
Class Instance
No Yes
Yes Yes
No Yes
