- Page 1 2010-12-10 5011699301-MTN1 Eaton Logic Controller ELCM TC Temperature Modules INSTRUCTION SHEET [Applicable Temperature modules] ELCM-TC04ANNN IL05004006E 002-1300620-02...
- Page 2 The ELCM-TC04ANNN temperature measurement module supports 4 channels of thermocouple temperature sensors (J-type, K-type, R-type, S-type, T-type, E-type, N-type, ±80mV) and converts these signals into 16-bit digital data. You can select temperatures in Celsius (resolution: 0.1°C) or Fahrenheit (resolution: 0.1°F). The data in the module may be accesses using the FROM/TO instructions, or you may read the average value of channels directly by using the MOV instruction (Please refer to allocation of special registers D9900 ~ D9999).
-
Page 3: External Wiring
61.5 Unit: mm External Wiring Thermocou ple Shiel ded ca ble *1 I1 - Volta ge i nput Shiel ded -80mV~80mV ca ble *1 I4 - Cold- Junction Compensation Termi nal o f power modul e DC/ DC System Converter groun ding Ω... -
Page 4: Functions Specifications
ELCM-TC04ANNN Max. rated power 1.2W, supplied by external power source consumption Connector IEC standard removable terminal block (Pin pitch: 5mm) Operation: 0°C~55°C (temp.), 50~95% (humidity), Pollution degree2 Operation/storage Storage: -25°C~70°C (temp.), 5~95% (humidity) Vibration/shock IEC61131-2, IEC 68-2-6 (TEST Fc)/ IEC61131-2 & IEC 68-2-27 immunity (TEST Ea) The modules are numbered from 0 to 7 automatically by their... -
Page 5: Control Register
ELCM- Voltage Celsius (°C) Fahrenheit (°F) input TC04ANNN 500VDC between digital circuits and Ground 500VDC between analog circuits and Ground Isolation 500VDC between analog circuits and digital circuits 500VDC between 24VDC and Ground 120VAC between analog channels Control Register CR# Attrib. - Page 6 CR# Attrib. Register content Description Adjusted Offset value of #28 O R/W Set the adjusted Offset value of Ch1 ~ Ch4. Default = K0 Adjusted Offset value of #29 O R/W Range: K-400 ~ K400 Temperature unit: set in CR#7 Adjusted Offset value of #30 O R/W Definition of Offset:...
- Page 7 Description CH2 Conversion Set value changing K16 (H’10) bit12 K4096(H’1000) bit4 error prohibited Communication CH3 Conversion K32 (H’20) bit5 bit13 K8192(H’2000) breakdown on next error module Note: Each error status is determined by the corresponding bit (b0 ~ b13) and there may be more than 2 errors occurring at the same time.
- Page 8 When ELCM-PH/ELCM-PA controllers use the ELCM-TC04ANNN, special registers are configured as shown below: Module Module Module Module Module Module Module Module Description Module D1320 D1321 D1322 D1323 D1324 D1325 D1326 D1327 Code CH1 average D9900 D9910 D9920 D9930 D9940 D9950 D9960 D9970 temperature...
- Page 9 Mode 2: R-type thermocouple Mode 4: T-type thermocouple Mode 3: S-type thermocouple Digital output Digital output +17,500 +3,900 (+31,820) (+7,340) Measured Measured -150 temperature temperature (-32 F) (-238 F) input input +390 0(-320) +1,750 (+734 F) (+3,182 F) -1,500(-2,380) ...
- Page 10 Mode 7: +8,000 Digital output -80mV +80mV Voltage input -8,000 Mode 7 of CR#2~ CR#5 -80mV ~ +80mV (-8000~8000) Offset (CR#34 ~ CR#37) Deviation digital value corresponds to 0mv - 9 -...
