Chapter 1 General Information

Introduction

Specially designed for the factory floor and other harsh industrial
environments, the IPC-6806 wallmount IPC chassis is ideal for system
integrators or users who require a compact, rugged PC/AT-compatible
system. The IPC-6806 features a 6-slot passive backplane and a
150-watt power supply. The chassis is only 6.5" wide and can be easily
mounted on panels or walls with the supplied brackets.

Specifications

• Construction: Heavy-duty steel
• Disk drive capacity: One 3½" FDD and one 3½" HDD
• Indicators: LEDs for power On/Off and HDD
• Controls: Reset switch on front panel
• Cooling fan: One 49-CFM fan on front panel with air filter
• Weight: 5.6 kg (12.3 lbs)
• Dimensions (W x D x H): 166 x 170 x 393 mm (6.5" x 6.7"x 15.5")
• Paint color: Pantone 415C
Passive backplane (PCA-6106)
• Slots: 6 ISA-bus, full-size
• PC board: 4-layer PCB with ground and power planes for reduced
noise and low power-supply impedance
• Indicators: LEDs for +5 V, +12 V, -5 V and -12 V
Passive backplane (PCA-6106P3)
• Slots: 2 ISA / 3 PCI / 1 PICMG slots
• PC board: 4-layer PCB with ground and power planes for reduced
noise and low power-supply impedance
• Indicators: LEDs for +5 V, +12 V, -5 V and -12 V
