  • Page 1 LT-6045SEC Rev. 0 Application Guide November 2016...

  • Page 3: Table Of Contents

    Table of Contents Introduction Working with the Fire Alarm Control Panel and the Configurator Connecting the Configurator to the Fire Alarm Control Panel ........2.1.1 Inserting the CodeMeter Key ..................2.1.2 Connecting the Computer ....................Sending a Job to the Fire Alarm Control Panel .............. Getting the Active Job from the Fire Alarm Control Panel ..........
  • Page 4 Table of Contents 5.1.3 Operators ........................5.1.4 Using brackets ........................ 5.1.5 Equation Box ........................5.1.6 Description Box ......................5.1.7 Comment Box ......................... Example of Advanced Logic with AND ................5.2.1 Creating a zone ......................5.2.2 Correlating the zone with an input using advanced logic ..........5.2.3 Correlating the zone with an output ................
  • Page 5 Table of Contents 8.1.4 Correlating the zone with an output ................Custom Intervals ......................Zone Latching Zone Latching Sequence ....................Creating a Zone Latching Sequence ................Creating a Latching Zone with a Timer ................10.0 Relay Pulsing 10.1 Relay Pulsing Sequence ....................10.2 Creating a Relay Pulsing Sequence ................
  • Page 6 Table of Contents 12.0 Cables 12.1 Maximum Recommended Cable Lengths ..............12.1.1 How to Calculate the Maximum Recommended Length ..........12.2 Fiber Optic Cables ......................12.3 Typical Optical Power Budget ..................12.3.1 Connecting Fiber Optic Cables ..................12.4 Ground Fault Reporting ....................12.5 Ground Fault Detection ....................
  • Page 7 Table of Contents 17.0 Connecting to a BACnet system 17.1 BACnet Objects ......................17.2 Setting up BACnet ......................17.2.1 Connecting the Ethernet cable ..................17.2.2 Configuring the Fire Alarm Control Panel ............... 17.2.3 Pinging the Fire Alarm Control Panel ................17.3 Generating Reports ......................
  • Page 8 Table of Contents 19.3.3 Correlations Pane ......................19.4 Job Tree ......................... 19.5 Job Details ........................19.5.1 Holidays .......................... 19.6 Network Node ......................... 19.6.1 Node Grouping ....................... 19.7 Base I/O .......................... 19.8 Main Display / LCD Annunciator ..................19.8.1 Passcodes ........................19.8.2 Access Levels .........................
  • Page 9 Table of Contents 19.37 Custom Intervals ......................19.38 Custom Timers ....................... 19.39 Input / Output Circuit Summary ..................19.40 Input Zones ........................19.41 LED Annunciator ......................19.42 Loop Details ........................19.43 Fire Phone Configuration ....................19.43.1 Adding an audio controller ....................19.43.2 Adding a fire phone module ....................
  • Page 10 List of Figures Figure 1 Connected CodeMeter key ..................... Figure 2 Disconnected CodeMeter key ..................Figure 3 Security Key Logon ......................Figure 4 Send Job ........................Figure 5 The job you are about to overwrite on the panel is not backed up on the local database Figure 6 The job has been successfully stored ................
  • Page 11 List of Figures Figure 44 Printed walk test report ....................Figure 45 Add WalkTest Area ......................Figure 46 New walk test area ......................Figure 47 Add Input Devices ......................Figure 48 Select items to add ......................Figure 49 MMX-2003-12NDS mounts in the MMX-BBX-1024DS enclosure ........Figure 50 MMX-2017-12NDS mounts in the MMX-BBX-1072A(R)DS Backbox ......
  • Page 12 List of Figures Figure 89 Queue Status ........................Figure 90 Advanced Panel Info ...................... Figure 91 Configuration Status ....................... Figure 92 Alarm Log ........................Figure 93 Event Log ........................Figure 94 TCP Socket Table ......................Figure 95 UDP Socket Table ......................Figure 96 ARP Table ........................
  • Page 13 List of Figures Figure 134 Display Firmware Data Structure ..................Figure 135 This job is protected against unintentional edits ............. Figure 136 This job version has already been built or downloaded to the panel ......Figure 137 New Job Version Information ..................Figure 138 Paste Special for loops ....................
  • Page 14 List of Tables Table 1 MMX System Limits ......................Table 2 Frame Count ........................Table 3 Chassis ........................... Table 4 Main Displays ......................... Table 5 Display Boards ....................... Table 6 Remote Annunciators ..................... Table 7 Paging and Fire Fighter Telephone Modules ..............Table 8 Network Controller Modules ...................

  • Page 15: Introduction

    Introduction This reference guide is for application engineers who build and configure the MMX Fire Alarm Control Panel. It covers MMX firmware and software version 12.

  • Page 16: Working With The Fire Alarm Control Panel And The Configurator

    Working with the Fire Alarm Control Panel and the Configurator This chapter covers the most important things you need to know about the Fire Alarm Control Panel and the Configurator. The Fire Alarm Control Panel network (also called the Fire Alarm Control Panel, the FACP, or the panel) is the system of networked panels that controls the fire detection and prevention system.

  • Page 17: Inserting The Codemeter Key

    Working with the Fire Alarm Control Panel and the Configurator 2.1.1 Inserting the CodeMeter Key The CodeMeter key is a USB flash drive that controls access to the Fire Alarm Control Panel. • Insert your CodeMeter key into the computer. The CodeMeter icon in the Windows system tray (the lower right-hand corner of the screen) turns blue.

  • Page 18: Sending A Job To The Fire Alarm Control Panel

    Working with the Fire Alarm Control Panel and the Configurator Sending a Job to the Fire Alarm Control Panel To send a job 1. Click Job > Open Job and open the job that you want to send. 2. In the Configurator, click Panel > Connect. 3.

  • Page 19: Getting The Active Job From The Fire Alarm Control Panel

    Working with the Fire Alarm Control Panel and the Configurator 6. Click Yes if you want to make this job the active job. A window appears saying that the job was successfully downloaded to the FACP. Figure 7 Job successfully downloaded 7.

  • Page 20: Exporting A Job

    Working with the Fire Alarm Control Panel and the Configurator A window appears saying that the job was successfully uploaded from the FACP. Figure 10 Job successfully uploaded 3. Click OK. Exporting a Job You can export jobs from the Configurator, and send them to other technicians or use them in other applications.

  • Page 21: Changing The Active Job

    Working with the Fire Alarm Control Panel and the Configurator The Manage Jobs Configuration on Panel window appears. Figure 11 Manage Jobs The FACP can hold three jobs in its memory. This window shows the jobs that are currently on the panel, and it shows the active job in orange.

  • Page 22: Changing The Active Job Using The Configurator

    Working with the Fire Alarm Control Panel and the Configurator 5. Press ENTER to confirm. The system changes the active job. 2.6.2 Changing the Active Job using the Configurator You can change the active job using the Configurator. This procedure changes the configuration for all the nodes that are currently Note: connected to the system.

  • Page 23: Getting Configuration Information From The Configurator

    Working with the Fire Alarm Control Panel and the Configurator 2.8.1 Getting Configuration Information from the Configurator To get configuration information from the Configurator 1. In the Configurator, click Panel > Connect. 2. Click Panel > Panel Information. The Panel Information window appears. Figure 12 Panel Information The name of the job that is currently active on the FACP.

  • Page 24: Getting Configuration Information From The Fire Alarm Control Panel

    Working with the Fire Alarm Control Panel and the Configurator Figure 13 Advanced Panel Information The number assigned to each node. Node The number for each CPU on the node. The type of CPU, for example a Main CPU, LCD Annuciator, Loop Type Controller, or Audio Controller.

  • Page 25: Restarting The Fire Alarm Control Panel

    The date when your key expires. If your key has expired or is about to ESD Expiry Date expire, contact Secutron technical support at 1-905-695-3545. The number assigned to the technician. Each technician in your Technician organization has a unique number.

  • Page 26: Performing A Network Restart Of The Fire Alarm Control Panel

    Working with the Fire Alarm Control Panel and the Configurator 2.10.1 Performing a Network Restart of the Fire Alarm Control Panel You must perform a network restart: • After you upgrade the firmware. • As the first step of troubleshooting. If a network restart does not solve the problem, you can perform a hard restart.

  • Page 27: Watchdog Jumpers

    Working with the Fire Alarm Control Panel and the Configurator See Figures 15 and 16 for pictures of a CPU. Figure 15 MMX-2003-12NDS board showing the CPU Figure 16 Close-up of a CPU 2. Set DIP switch 8 to ON (the up position) on all the components that have CPUs. 3.
  • Page 28 Working with the Fire Alarm Control Panel and the Configurator watchdog jumper must be closed. If you are experiencing problems, for example if the system does not restart properly, make sure that the watchdog jumper is closed. Watchdog jumpers are labeled as follows: •...

  • Page 29: Upgrading Firmware

    Upgrading Firmware To upgrade the firmware on a Fire Alarm Control Panel, you need the following items: • Windows computer with a serial or USB port • Serial cable or USB to serial cable • UIMA cable • Registered CodeMeter key •...

  • Page 30: Figure 18 Upgrade Firmware On Panel

    Upgrading Firmware 7. In the Configurator, click Panel > Connect. 8. Click Panel > Upgrade Firmware. 9. Navigate to the location where the firmware file is stored, and then click Open. The Upgrade Firmware on Panel window appears. Figure 18 Upgrade firmware on panel •...
  • Page 31 Upgrading Firmware 11. Click OK. After you have upgraded the firmware, you must restart the system. 12. Follow the instructions in section 2.10.1 on page 26. 13. After the system has restarted, get the advanced panel information to confirm that the system has the latest firmware.

  • Page 32: System Limits

    System Limits MMX System Limits Unless otherwise noted, these limits apply to software and firmware version 12. Table 1 MMX System Limits Device Maximum number Nodes 12 per node: 1 on the main board + 4 local per node (quad loop adders) CPUs + 7 remote per node (annunciators) 128 CPUs in total per system...

  • Page 33: Frames

    System Limits Table 1 MMX System Limits (Continued) Device Maximum number Inputs correlated to 1800 per CPU Remote Zones 1800 per CPU Remote Output Zones 1 per system UDACTs 96 per system Custom Audio Clips Entries in one audio message (audio clips 32 per system and repeat loops together)

  • Page 34: Table 2 Frame Count

    System Limits Table 2 lists the number of frames used and provided by each device. Table 2 Frame Count Name Description Name in the Frames Used Frames Available Configurator Narrow Main DSPL-420 Display (4 lines by Main Display 20 characters) Narrow Graphic DSPL-2440 Main Display...
  • Page 35 System Limits Table 2 Frame Count (Continued) Name Description Name in the Frames Used Frames Available Configurator Network Telephone QMT-5302N(V) Master Telephone Control Unit...

  • Page 36: Advanced Logic

    Advanced Logic Advanced logic uses logical operators such as AND, OR, and NOT, and inputs such as zones and detectors. To use advanced logic, you create a zone and add an equation in the Advanced Logic Editor. When the result of the equation is true, the associated output activates. Attention: Do not apply an equation directly to an output.

  • Page 37: Inputs List

    Advanced Logic 5.1.1 Inputs List The Inputs list is a list of all inputs that you can use in equations. The inputs are: • Local input circuits • Local input zones • Remote input zones • Custom Intervals • Custom Timers •...

  • Page 38: Device Status

    Advanced Logic 5.1.2 Device Status The Device Status menu applies a status (also called a mask) to an input. If you apply a status to an input, then the equation becomes true when the input has that status. The statuses are: :A –...

  • Page 39: Using Brackets

    Advanced Logic Syntax: ANY n OF (input 1, input 2, ... input x) where n is a positive integer An equation with ANY is true if any one of the following inputs are true. For example, the equation ANY 1 OF (01-00-02-IN-003:A, 01-00-02-IN-004:A) is true if any one of the inputs (01-00-02-IN-003 or 01-00-02-IN-004) is in alarm.

  • Page 40: Equation Box

    Advanced Logic This equation is true if **-**-**-ZS-000 and either **-**-**-ZS-001 or **-**-**-ZS-002 are pressed. The last 2 inputs are grouped, so one of them must be active at the same time that the first input is active. The equation is not true if **-**-**-ZS-002 is pressed by itself, because it is part of a group. 5.1.5 Equation Box You can type equations in the Equation Box.

  • Page 41: Creating A Zone

    Advanced Logic 5.2.1 Creating a zone To create a zone 1. Select Input Zones (under Base I/O) in the job tree on the left side of the Configurator window. 2. Click the Insert menu, and then click Add Zone. The Add Zone window appears. 3.

  • Page 42: Example Of Advanced Logic With Or

    Advanced Logic Example of Advanced Logic with OR This example shows how to create an advanced logic equation with the OR operator. This is almost the same as the previous example. The only difference is the equation itself. To create an equation with OR 1.

  • Page 43: Example Of Advanced Logic With Any

    Advanced Logic 8. Click the NOT button. 9. Click :A (alarm) in the Device Status menu. 10. Select Input 2, and then click the > button to move the device to the Equation box. The equation should look like this: 06-03-11-IN-101:A AND NOT 06-03-11-IN-102:A 11.

  • Page 44: Example Of Advanced Logic With Equ

    Advanced Logic 14. Type a description in the Description box, and then type a comment in the Comments box. 15. Click OK to close the Advanced Logic Editor. 16. Right-click the zone, then click Add Correlations. 17. Add an output, and then click Close. Monitor Zone 4 will become active when any 2 of the 3 devices go into alarm.

  • Page 45: Example Of Advanced Logic With Mass Notification

    Advanced Logic The equation in zone 3 looks like this: 01-00-L0-SM-005:A AND 01-00-L0-SM-006:A AND 01-00-L0-SM-007:A This equation is common to relays 1, 2, 3, and 4. Relay 1: 01-00-**-IZ-003:A AND NOT 01-00-L0-SM-008:A Relay 2: 01-00-**-IZ-003:A AND NOT 01-00-L0-SM-009:A Relay 3: 01-00-**-IZ-003:A AND NOT 01-00-L0-SM-010:A Relay 4: 01-00-**-IZ-003:A AND NOT 01-00-L0-SM-011:A...

  • Page 46: Assigning Switches To The Groups

    Advanced Logic To assign the nodes to the groups 1. Create two nodes, and tag them Fire Panel and MNS Panel. 2. Select the Fire Panel node. 3. In the right pane, scroll down to the Node Grouping section, and then click Add to create a group.

  • Page 47: Using Advanced Logic To Communicate Between Groups

    Advanced Logic To assign zones to the nodes 1. Select Input Zones under the Fire Panel node. 2. Create a zone, and then tag it Fire Input Zone. 3. Correlate this zone to the fire input devices and the fire output signals. 4.

  • Page 48: Creating A Zone And Inputs

    Advanced Logic (01-00-02-IN-001:A AND 01-00-02-IN-002:A) OR ANY 1 OF (01-00-02-IN-003:A, 01-00-02-IN-004:A) OR (01-00-02-IN-103:L EQU ALARM_LEVEL1 AND NOT 01-00-02-IN-103:L EQU ALARM_LEVEL2) 01-00-02-IN-001 - Example Input 1 (detector) 01-00-02-IN-002 - Example Input 2 (detector) 01-00-02-IN-003 - Example Input 2 (detector) 01-00-02-IN-004 - Example Input 5 (detector) 01-00-02-IN-103 - Example Input 4 (4-20 mA input module) The equation is true when Example Input 1 and Example Input 2 are in alarm, or either Example Input 3 or Example Input 5 are in alarm, or Example Input 4 is equal to...
  • Page 49 Advanced Logic 12. Click the OR button. 13. Type ( (an open bracket). 14. Click the ANY button. 15. Select :A (alarm) in the Device Status menu, and then select the device tagged Example Input 3. 16. Click the > button. Example Input 3 appears in the Equation box.

  • Page 50: Correlating The Zone With An Output

    Advanced Logic 30. Type a comment in the comment box, and then click OK. 31. Click OK to close the Advanced Logic Editor. 5.9.4 Correlating the zone with an output To correlate the zone with an output 1. Right-click an output in the same group as Virtual Alarm Zone 1, and then click Add Correlations.

  • Page 51: Testing Uukl Devices

    Testing UUKL Devices The goal of UUKL is prevent smoke from entering other floors (or zones) by pressurizing them to evacuate the smoke from the smoked zone. This chapter describes how to create an interval for testing UUKL devices. Attention: You should be familiar with advanced logic before following the instructions in this chapter.

  • Page 52: Figure 24 Advanced Logic Equation For Uukl Test Interval

    Testing UUKL Devices Figure 24 Advanced logic equation for UUKL test interval 5. Click OK.

  • Page 53: Walk Test

    Walk Test The walk test allows an operator to test the system or part of the system. While the system is in walk test mode, devices can be tested without causing a real alarm situation. There are two kinds of walk test: •...

  • Page 54: Results

    Walk Test 4. Press the UP or DOWN button to change the walk test termination timeout. The valid range is from 1 hour to 12 hours, and the default value is 6 hours. - Walktest - Timeout 6 hours Figure 28 Walk test termination timeout 5.

  • Page 55: Assisted Walk Test

    Walk Test To browse the devices in the walk test list • Press the UP and DOWN buttons. The display indicates if the device is already tested (A:nnn for the total number of alarm events and T:nnn for the total number of trouble events reported on the device). Nnn Lnn Adrnnnnnnnn A:nnn T:nnn Tag 1...

  • Page 56: Results

    Walk Test To start an assisted walk test 1. Enter walk test mode from the command menu. - Command Menu - 2 Bypass 3 Walktest 4 Day/night mode Figure 33 Enter walk test 2. Select 1 for assisted walk test. - Walktest - 1 Assisted 2 Walktest report...

  • Page 57: Walk Test Report

    Walk Test • D - Number of duplicate events recorded from the moment the walk test started. The duplicate event counter is separate for alarm events and for trouble events. • R - Number of remaining events until the walk test is completed. The remaining event counter is separate for alarm events and for trouble events.

  • Page 58: Figure 39 Enter Walk Test

    Walk Test To view the results of the last walk test 1. Enter walk test mode from the command menu. - Command Menu - 2 Bypass 3 Walktest 4 Day/night mode Figure 39 Enter walk test 2. Select 2 for walk test report. - Walktest - 1 One Man 2 Walktest report...

  • Page 59: Figure 44 Printed Walk Test Report

    Walk Test 5. Press the INFO button to switch the display to the general information for the walk test list. Figure 44 shows an example of the printed walk test results. ---------------- - Walktest - - Jun 11,2015 15:22:07 --------------- ------------------------- Job Name: walktest ------------------------ ------------------------------ Job version: 1.0 -----------------------------...

  • Page 60: Configuring Walk Test Areas

    Walk Test Configuring Walk Test Areas Walk test areas are areas containing devices to be tested. Walk test areas let you test devices in one area while leaving the other areas active. You create walk test areas in the Configurator. In order to use the assisted walk test, the system must have walk test areas configured.

  • Page 61: Figure 47 Add Input Devices

    Walk Test 4. Right-click the walk test area, and then select Add Input Devices. Figure 47 Add Input Devices The Select items to add window appears. Figure 48 Select items to add 5. Select the input devices that you want to add to this walk test area, and then click Add. 6.

  • Page 62: Custom Timers And Intervals

    Custom Timers and Intervals This chapter describes how to create custom timers and intervals with the Configurator. Timers and intervals let you control when and for how long a certain operation takes place. For example, you can use a timer to delay a vent fan until the damper has had time to open, or to delay the activation of compressors so that they do not all activate at once and overload the system.

  • Page 63: Correlating The Timer With An Input

    Custom Timers and Intervals 8.1.2 Correlating the timer with an input To correlate the timer with an input 1. Select the timer that you just created. 2. Click Edit in the Advanced Logic window at the bottom of the Configurator window. The Advanced Logic Editor appears.

  • Page 64: Correlating The Zone With An Output

    Custom Timers and Intervals 8.1.4 Correlating the zone with an output To correlate the zone with an output 1. Right-click the zone, then click Add Correlations. 2. Add an output, and then click Close. You have successfully created a timer. The input you specified in section 8.1.2 starts the timer. The zone you created in section 8.1.3 becomes active when the equation becomes true (when the timer expires).
  • Page 65 Custom Timers and Intervals 9. Type a description in the Description box, and then type a comment in the Comments box. 10. Click OK to close the Advanced Logic Editor. 11. Right-click the zone, then click Add Correlations. 12. Add an output, and then click Close. Trouble Zone 1 will become active when the current time is not within the interval.

  • Page 66: Zone Latching

    Zone Latching “Latching” and “non-latching” refer to the behavior of an input. When a non-latching input initiates an alarm, the alarm stays active until the input goes back to normal status. In contrast, when a latching input initiates an alarm, the alarm stays active until the system is reset. With advanced logic, you can latch normally non-latching zones such as monitor, trouble, and non-latching supervisory zones.

  • Page 67: Creating A Zone Latching Sequence

    Zone Latching Creating a Zone Latching Sequence To create a zone latching sequence 1. Create an initiating device. This can be a monitor zone, input circuit, or a status such as All Call. 2. Create a non-latching zone such as a monitor zone. This will become a latching zone. 3.

  • Page 68: Relay Pulsing

    10.0 Relay Pulsing Relay pulsing refers to a configuration where a relay turns on (closes) and then turns off (opens) after a single switch press. An example of relay pulsing is the activation of a pre- recorded digital message with the first switch press, and then the deactivation of the message with the second switch press, simulating a maintained switch.
  • Page 69 Relay Pulsing TIMER_EXPIRED) 01-00-**-IZ-007 – Input Switch zone 01-00-**-IZ-011 – Latch A zone **-**-**-TM-021 – Latch B Timer Latch B Timer is included in the equation so that Latch A will unlatch (become inactive) during the second pulse (when Latch B Timer starts). 8.

  • Page 70: Relay Pulsing With Multiple Switches

    Relay Pulsing 10.3 Relay Pulsing with Multiple Switches If you want to use multiple switches, you can add an equation to the monitor zone to reduce interference between switches. Refer to the example below: 01-00-00-IN-008 AND NOT ANY 1 OF ( 01-00-**-IZ-008 , 01-00-**-IZ-009 , 01-00-**-IZ-010 ) 01-00-00-IN-008 –...

  • Page 71: Hardware Layouts

    11.0 Hardware Layouts The information in this chapter is for reference only and is subject to change Note: without notice. For complete details refer to the respective manual. The MMX Fire Alarm Control System contains two major types of nodes: Fire Nodes and Mass Notification Nodes.

  • Page 72: Chassis

    Hardware Layouts 11.2 Chassis Table 3 Chassis Name Description Mounts in Number of Notes Additional Displays or Adder Modules MMX-2003-12NDS Slot 3 is reserved for MR- FNC-2000 2300-PR (Polarity Reversal/ Network City Tie Module) or UDACT- Controller 300A (Dialer) if required Module and 2 12 Amp MMX-BBX-...

  • Page 73: Display Modules

    Hardware Layouts Table 3 Chassis (Continued) Name Description Mounts in Number of Notes Additional Displays or Adder Modules FNC-2000 MMX-2017-12NDS Network Controller Slot 3 is reserved for MR- Module and 2 2300-PR or UDACT-300A if adder modules 12 Amp Mid- required MMX-BBX- over the main...

  • Page 74: Main Displays

    Hardware Layouts 11.3.1 Main Displays Table 4 Main Displays Name Description Mounts in MMX-BBX-1072A(R)DS DSPL-420 BB-5008(R) BB-5014(R) MMX-BBX-FXMNS Narrow Main Display (4 MMX-2003-12NDS lines by 20 characters) MMX-2009-12NDS MMX-2017-12NDS ECX-0012 MMX-2000MNS MMX-BBX-1072A(R)DS DSPL-2440 BB-5008(R) BB-5014 MMX-BBX-FXMNS Narrow Graphic Display MMX-2003-12NDS MMX-2009-12NDS MMX-2017-12NDS ECX-0012...

  • Page 75: Remote Annunciators

    Hardware Layouts Table 5 Display Boards (Continued) Name Description Mounts in MMX-2003-12NDS FDX-008/KI MMX-2003-12NXTDS MMX-2017-12NDS MMX-2009-12NDS Smoke Control Fan Damper Module, 8 ECX-0012 zones BB-5008(R) BB-5014 MMX-BB-1000 series MMX-BBX-FXMNS 11.3.3 Remote Annunciators Remote annunciators are also called display modules or display adders. Table 6 Remote Annunciators Name Description...
  • Page 76 Hardware Layouts Table 6 Remote Annunciators (Continued) Name Description Mounts in MMX-2003-12NDS RAX-1048TZDS MMX-2003-12NXTDS MMX-2017-12NDS MMX-2009-12NDS Adder Annunciator with 48 bi- coloured LEDs and 32 trouble ECX-0012 LEDs BB-5008(R) BB-5014 MMX-BB-1000 series MMX-BBX-FXMNS MMX-BB-1000 series RAXN-LCD BB-5008(R) BB-5014 Remote Shared Display Annunciator MMX-BBX-FXMNS MMX-LOC...

  • Page 77: Paging And Fire Fighter Telephone Modules

    Hardware Layouts Table 6 Remote Annunciators (Continued) Name Description Mounts in RTI-1 Remote Trouble Indicator (single Mounts to a single gang LED and trouble buzzer) electrical box. BB-5008 MGD-32 Master Graphic Driver Module with 32 supervised outputs BB-5014 BB-5008 AGD-048 Adder Graphic Module with 48 supervised outputs BB-5014...

  • Page 78: Adder Modules

    Hardware Layouts Table 7 Paging and Fire Fighter Telephone Modules (Continued) Name Description Mounts in QMT-5302N BB-5008 Network Telephone Control Unit BB-5014 MMX-BB-1000 series QMT-5302NV Network Telephone Control Unit MMX-BBX-FXMNS (Vertical Mount) QAZT-5302DS BB-5008 Addressable Telephone Selector BB-5014 Panel MMX-BB-1000 series 11.5 Adder Modules These modules can be installed inside any node with adder module slots.

  • Page 79: Adder Modules

    Hardware Layouts Table 8 Network Controller Modules (Continued) Name Description Mounts in Notes MMX-2003-12NDS FOM-2000-SP MMX-2009-12NDS Fibre Optic Network MMX-2017-12NDS 1 per node Adder Module ECX-0012 MMX-2000MNS QMB-5000N ANC-5000 Audio Network BB-5008 and BB- 1 per node Controller Module 5014, positions 4 - 9 MMX-2009-12NDS QMB-5000N TNC-5000...
  • Page 80 Hardware Layouts Table 9 Controller Cards (Continued) Name Description Mounts in Notes MMX-2003-12NDS DM-1008A MMX-2003- 12NXTDS 8 per built-in loop 8 Initiating Circuit MMX-2009-12NDS Module 16 per node MMX-2017-12NDS ECX-0012 MMX-2000MNS MMX-2003-12NDS SGM-1004A MMX-2003- 12NXTDS 4 Notification 8 per built-in loop MMX-2009-12NDS Appliance Circuit 16 per node...

  • Page 81: Booster Power Supplies

    Hardware Layouts 11.6 Booster Power Supplies Table 10 Booster Power Supplies Name Description Mounts in INX-10AC BB-5014 Addressable Booster Power MMX-BBX-FXMNS Supply BB-5008(R) 11.7 Backboxes Backboxes, also called enclosures, are large steel cabinets that hold chassis, displays, and adder modules. 11.7.1 MMX-BBX-1024R Fire Node Backbox The MMX-BBX-1024R is the smallest backbox available.

  • Page 82: Mmx-Bbx-1072A(R)Ds Fire Node Backbox

    Hardware Layouts Table 11 MMX-BBX-1024R Name Description Holds Dimensions MMX-BBX-1024DS(R) MMX-2003-12NDS Black backbox, white or 26.3” H x 14.8” W x red door 4.6” D 17 Ah battery pack 11.7.2 MMX-BBX-1072A(R)DS Fire Node Backbox The MMX-BBX-1072A(R)DS backbox is larger than the MMX-BBX-1024R. It contains the MMX-2017-12NDS Mid-Size Main Chassis along with the batteries for emergency operation.

  • Page 83: Bb-5008 Fire Node Backbox

    Hardware Layouts Table 12 BBX-1072A(R)DS Name Description Holds Dimensions MMX-BBX- 1072A(R)DS MMX-2017-12NDS DSPL-420 Black backbox, white or 33.9” H x 26.4” W x red door 6.5” D DSPL-2440 24 Ah battery pack 11.7.3 BB-5008 Fire Node Backbox The BB-5008 backbox is larger than the MMX-BBX-1072A(R)DS. It can use the MMX-2009- 12NDS Large Main Chassis combined with ECX-0012 Expander Chassis for additional display modules and the CCH-5008/CCH-5014 Custom Mounting Kits for paging and fire fighter telephone modules.

  • Page 84: Figure 52 Exc-0012 Mounts And Occupies 2 Display Positions In Bb-5008 Or Bb-5014

    Hardware Layouts Exterior View Interior View Cutout to mount Cutout to mount display module display module Supports 2 Display Modules. Supports 12 Adder Modules. The backplate can support 12 Adder Modules or any 2 of the following 3 options: 6 Adder Modules, 1 Main Board and 3 Adder Modules, 1 Telephone Network Card and 1 Audio Network Card Figure 52...

  • Page 85: Bb-5014 Fire Node Backbox

    Hardware Layouts 11.7.4 BB-5014 Fire Node Backbox The BB-5014 backbox is the largest available backbox. It can use the MMX-2009-12NDS Large Main Chassis combined with ECX-0012 Expander Chassis for additional display modules and the CCH-5008/CCH-5014 Custom Mounting Kits for paging and fire fighter telephone modules.

  • Page 86: Ecx-0012 Expander Chassis For Mmx-2009-12Nds

    Hardware Layouts 11.7.5 ECX-0012 Expander chassis for MMX-2009-12NDS The backplate can support 12 adder modules or any 2 of the following 3 options: • 6 adder modules • 1 main board and 3 adder modules • 1 telephone network module and 1 audio network module. Cutout to mount Cutout to mount display module...

  • Page 87: Bb-5008 And Bb-5014 Sample Layouts

    Hardware Layouts 11.7.7 BB-5008 and BB-5014 sample layouts The modular nature of a fire node allows for many different configurations and combinations of modules depending on the requirements of the job. The figures below show sample layouts for the BB-5008 and BB-5014, but many other layouts are possible. BB-5008 Sample Layout Interior View Exterior View...

  • Page 88: Backboxes For The Raxn-Lcd And Raxn-Lcdg

    Hardware Layouts BB-5014 Sample Layout Interior View Exterior View Cutout to mount Cutout to mount any display or any display or paging module paging module Cutout to mount Cutout to mount any display any display module module Cutout to mount Cutout to mount any display any display...

  • Page 89: Mmx-Bbx-Fxmns Mass Notification Node Backbox

    Hardware Layouts 11.8 MMX-BBX-FXMNS Mass Notification Node Backbox The MMX-BBX-FXMNS backbox is used for the mass notification node. It can hold 2 paging modules, 9 adder modules and 7 display modules as shown in Figure 58. It also supports the addition of 4 audio amplifiers along with audio and telephone networking modules.

  • Page 90: Bbx-Mnsxp Multi-Purpose Backbox

    Hardware Layouts 11.9 BBX-MNSXP Multi-Purpose Backbox This backbox can provide additional audio amplification for speakers and strobes. It can hold up to 7 amplifier boards and 3 INX-10AC Intelligent NAC Expander/Power Supplies. The outer dimensions are 62.75” X 27.5” X 9”. 10 AWG Tinned Copper Ground Strap Rail for mounting...

  • Page 91: 11.10 Mmx-Loc Local Operating Console

    Hardware Layouts IM-10A and/or CR-6A and/or CZ-6A (up to 6 total ) Batteries INX-10AC Figure 60 NAC Expander Installation into BBX-MNSXP with CH-994B Internal Chassis 11.10 MMX-LOC Local Operating Console These operating consoles are intended for use in mass notification. They can mount 3 modules on the deadfront door.

  • Page 92: Figure 61 Mmx-Loc

    Hardware Layouts Note that the deadfront and door can be installed such that they open either to the left or to the right as required. The outer dimensions of the MMX-LOC fit within 25.0” X 15.0” X 7.0”. RAXN-LCD LCD Network Annunciator FDS-008 Fan/Damper...

  • Page 93: 11.10.1 Audio Cabinets

    Hardware Layouts 11.10.1 Audio Cabinets Table 16 Audio Cabinets Name Description Holds Dimensions MMX-QBB- 5001(R) 1 QMB-5000B (space for 1 ANC-5000, 1 TNC-5000, and 7 amplifier boards) Expansion Audio 24.25” H x 41” W x 8” D Cabinet 1 QPS-5000N power supply 1 QBC-5000N battery charger...

  • Page 94: 11.10.2 Amplifier Bins

    Hardware Layouts 11.10.2 Amplifier Bins An amplifier bin, also called a card cage, holds amplifier boards and the ANC-5000 Audio Controller board. It is mounted inside an audio cabinet. You need an ANC-5000 Audio Controller only in the first bin. Table 17 Amplifier Bins Name Description...
  • Page 95 Hardware Layouts Table 18 Amplifier Cards (Continued) Name Description Mounts in MMX-QBB-5001 QAA-5160-70/25 One 60 W speaker output, 70 V or 25 V MMX-BBX-FXMNS...

  • Page 96: Cables

    If the cable you are using is not listed in Table 19, refer to section 12.1.1 on page 97 to calculate the maximum recommended length for a cable segment based on brand of cable. If you are experiencing signal loss or degradation, contact Secutron Technical Support for assistance: 1-905-695-3545 Email techsupport@mircom.com...

  • Page 97: How To Calculate The Maximum Recommended Length

    Cables Table 19 Maximum Recommended Cable Lengths (Continued) Manufacturer Model Type Recommended maximum length per cable segment (point-to- point) Metres Feet 16 AWG, 2 conductors, Draka Lifeline FAS-2C/16NS 2050 twisted, non-shielded 16 AWG, 2 conductors, Draka Lifeline FAS-2C/16OS 1180 twisted, shielded 18 AWG, 2 conductors, Electro Cables 7241802BFT4...

  • Page 98: Fiber Optic Cables

    A cable with a capacitance higher than 35 nF (nanofarads) can lead to signal distortion. Secutron has looked at different brands of cables and calculated the length of each cable at 35 nF. This is the maximum recommended length for each brand of cable.

  • Page 99: Typical Optical Power Budget

    Cables The numbers represent the diameter of the core/cladding in micrometers (microns). 12.3 Typical Optical Power Budget • 50/125 μm: 9.6 dB • 62.5/125 μm: 15 dB 12.3.1 Connecting Fiber Optic Cables The FOM-2000-SP Fiber Optics Network Module has 4 connections: RX2, RX1, TX2, and TX1.

  • Page 100: Ground Fault Reporting

    12.4 Ground Fault Reporting The MMX system reports ground faults as required by UL, ULC, and FM. Secutron has enhanced ground fault reporting to aid the technician in identifying which lead of a pair of wires is in contact with the ground. To this end, the ground fault report on the panel includes information about polarity (positive or negative).

  • Page 101: Ground Fault Detection

    Cables • NAC circuits: The polarity of the ground fault is reversed in the panel report because in normal supervisory condition, the NAC circuits are driven in the opposite polarity. • Annunciator and network connections that use electrical industry standard RS- 485 connections: The panel reports a ground fault on either lead of these connections as negative.

  • Page 102: Addressable Loop Interference On Phone Handset Lines

    Phone Handset Lines Addressable loops can cause noise on the phone handsets connected to the FACP, especially on handsets connected to System Sensor addressable modules. Secutron has several recommendations for reducing this noise. Keep these recommendations in mind before you start a job.

  • Page 103: Use Shielded Wiring

    Addressable Loop Interference on Phone Handset Lines 13.4 Use Shielded Wiring • Use 18 gauge shielded twisted pair cables for the connections between TNC-5000 telephone bus terminals, and for the connections between the addressable modules. • Use shielded cables for the connections between the addressable modules and the telephone handsets, if possible.

  • Page 104: Figure 64 Telephones And Addressable Modules Showing Shielded Wiring (Class A)

    Addressable Loop Interference on Phone Handset Lines • For class B wiring, leave the shield unconnected at the end of the line. twist-on connector Shield twist-on connector twist-on connector Shield Shield LAST Firephone Module MIX-M500FP(A) twist-on connector Shield twist-on connector twist-on connector Shield Shield...

  • Page 105: Keep Modules Close To The Handsets

    Addressable Loop Interference on Phone Handset Lines 13.5 Keep Modules Close to the Handsets • Install the handsets as close as possible to the modules. A shorter cable will reduce interference. • If you cannot install the handsets close to the modules, use shielded cables between the telephone modules and the handsets.

  • Page 106: Mass Notification System Introduction

    14.0 Mass Notification System Introduction The MMX Mass Notification System (MNS) allows announcements and notifications outside of regular fire announcements. For example, MNS can be used for weather warnings or toxic chemical alerts, and these announcements have a higher priority than fire announcements. The fire control system can also override the MNS.

  • Page 107: Conflicts With Virtual Zones

    Mass Notification System Introduction Even though the MNS has a fire monitoring component, it cannot control fire devices. Governing bodies such as UL/ULC require that MNS and fire control systems be grouped separately in the software. The input and output devices for fire and MNS must be in different zones and these zones must be in different groups.
  • Page 108 Mass Notification System Introduction To set priority for a zone or a switch 1. In the Configurator, double-click in the Priority column for the zone or switch. 2. Click a priority in the pulldown menu. This number is the priority given to digital messages that are correlated with this zone or switch.

  • Page 109: Autonomous Control Unit And Local Operating Consoles

    15.0 Autonomous Control Unit and Local Operating Consoles The Autonomous Control Unit (ACU) and the MMX Local Operating Consoles (MMX-LOCs) connect to the MMX Mass Notification System (MNS) remotely. The MNS uses the ACU and the MMX-LOCs to broadcast live announcements and pre-recorded digital messages to multiple locations in a building.

  • Page 110: Figure 68 Acu And Loc Configuration

    Autonomous Control Unit and Local Operating Consoles For example, a priority of 10% assigned to a zone switch on the ACU’s IPS switch adder module has a higher priority than a priority of 90% assigned to a zone correlated to the input module used by the MMX-LOC.

  • Page 111: Acu Operation

    Autonomous Control Unit and Local Operating Consoles Figure 69 Zone Priorities 15.4 ACU Operation To broadcast a pre-recorded digital message: • Press a button on the selector with the appropriate message. Buttons should be labelled to indicate the content of the message. The message will be broadcasted and will loop continuously until the system is reset or a higher priority operation is performed.
  • Page 112 Autonomous Control Unit and Local Operating Consoles Only one microphone can be used at a time. If the Page Ready LED is on before the microphone is removed from the receiver, then another microphone is in use. If the LED is off then there is no microphone in use. If the LED turns on only after the paging microphone is removed, then that microphone is now active.

  • Page 113: Digital Messages

    16.0 Digital Messages A digital message is a pre-recorded announcement or alarm tone. You compose a digital message by combining clips (audio files) into a composition. You can have up to 96 digital messages used in correlations per job. Note: 16.1 Creating a Digital Message To create a digital message...

  • Page 114: Figure 71 The Audio Setup Window

    Digital Messages The Audio Setup window appears. Figure 71 The Audio Setup window 2. Click the Manage Messages button. The Manage Messages window appears. Figure 72 The Manage Messages window The Manage Messages window lists the compositions that are currently in the system. You can add a new composition, or edit or remove an existing composition.

  • Page 115: Figure 73 Audio Compose Message

    Digital Messages 3. Click the Add button to create a new composition. The Audio Compose Message window appears. The left side of the window lists the available clips (audio files that you can combine into compositions). Several clips are included by default; they are listed as Built-In. The right side of the window shows the current composition.

  • Page 116: Clips And Nested Loops

    Digital Messages 16.2 Clips and Nested Loops Each clip is part of a loop. The loop is marked by the words Repeat Count and the curved arrow. Clips are marked by a speaker icon. The Audio Message Composer lets you create nested loops. If one loop is nested inside another, then the inside loop will play a specified number of times for every time the outside loop plays.
  • Page 117 Digital Messages To reorder clips within a loop • Select the clip, and then click the Up and Down buttons. You can move a clip up or down within a loop, but you cannot move it outside a Note: loop. To reorder loops •...

  • Page 118: Nested Loop Example

    Digital Messages 16.3 Nested Loop Example Figure 75 shows a composition with nested loops. In this composition, clip A plays twice (Loop 3), then clip B plays 3 times (Loop 4). These clips form a loop which repeats 4 times (Loop 2). Then clip C plays 3 times (Loop 5).

  • Page 119: Configuring Mmx To Use Your New Composition

    Digital Messages 13. Select Loop 5, then select clip C in the Audio Clips list, then click the >> button to move clip A to the Composition list. Clip A appears inside Loop 5. 14. The composition should look like this (Figure 76): Loop 1 Loop 5 Loop 2...

  • Page 120: Connecting To A Bacnet System

    17.0 Connecting to a BACnet system BACnet stands for Building Automation and Control Networks (http://www.bacnet.org). It is a communication protocol for monitoring and controlling different building regulation systems, which include heating, ventilation, lighting control, access control, and fire detection systems. The BACnet protocol uses a common communication format to let these different systems communicate with each other.

  • Page 121: Setting Up Bacnet

    Connecting to a BACnet system 17.2 Setting up BACnet You must purchase a BACnet license in order to use MMX with BACnet. You Note: must purchase one license for each job. To set up the BACnet server you must: • Connect the Ethernet cable.

  • Page 122: Figure 78 Network Node Info - Bacnet

    Connecting to a BACnet system The Network Node Info appears on the right. Figure 78 Network Node Info - BACnet 4. Type the static IP address, subnet mask and default gateway. Each node on the TCP/IP network requires its own IP (Internet Protocol) address. The IP address must be unique to the node and it must not be used by any other device on the TCP/IP network.

  • Page 123: Pinging The Fire Alarm Control Panel

    Connecting to a BACnet system 9. Check Supervise Ethernet Connection if necessary. This creates a trouble event if the node does not detect an Ethernet connection. 10. Click Panel > Send Job to send the job to the Fire Alarm Control Panel. 17.2.3 Pinging the Fire Alarm Control Panel Before attempting to connect BACnet software to the MMX system, ensure that there is a...

  • Page 124: Generating Reports

    Connecting to a BACnet system Figure 80 Unsuccessful ping 17.3 Generating Reports The Configurator can generate a BACnet report that includes the object ID of each object, and other identifying information such as node, CPU and loop number. To generate a report 1.

  • Page 125: Figure 81 Bacnet Report

    Connecting to a BACnet system Figure 81 shows the report. Figure 81 BACnet Report The first column lists the BACnet ID of each object in the MMX system. • The NodeNo, CPUNo, and LoopNo columns describe which Node, CPU and Loop each object is on.

  • Page 126: Object Types

    Connecting to a BACnet system 17.4 Object Types Table 20 shows how MMX classifies its devices according to the BACnet object types. Table 20 Object Types Object Type Fire Device Types Conventional Input, System Status, Page Select Switches, Manual Binary Input Control Switches, Miscellaneous Input Circuits Ion Detector, Photo Detector, Heat Detector, Laser Detector, Analog Input and...

  • Page 127: Dynamic Properties

    Connecting to a BACnet system 17.5.1 Dynamic Properties Each dynamic property uses different types of information as the values. The values also vary depending on the kind of object. Binary Input Property Value Present Value active or inactive Status Flags a Boolean array [_,_,_,_] - each value in the array represents the presence (1) or absence (0) of an Alarm, Fault, Override or Out of Service respectively...

  • Page 128: Cas Bacnet Explorer

    Connecting to a BACnet system Binary Output Property Value Present Value active or inactive Status Flags a Boolean array [_,_,_,_] - each value in the array represents the presence (1) or absence (0) of an Alarm, Fault, Override or Out of Service respectively Event State normal, fault or off normal...

  • Page 129: Visual Test Shell

    Connecting to a BACnet system for confirming the presence and availability of all the objects associated with the FACP and it must be performed before any FACP devices can be monitored. 1. Press the Discover button and a Discover dialogue box will appear. 2.

  • Page 130: Configuring Device, Port And Name Settings

    Connecting to a BACnet system 17.7.1 Configuring Device, Port and Name Settings 1. From the taskbar select Edit then select Device. The Device Configuration window appears. 2. Enter a name for the BACnet device in the Name field and its Device ID in the Instance field.

  • Page 131: Monitoring Objects

    Connecting to a BACnet system 17.7.4 Monitoring Objects Objects can be monitored by retrieving the current value of any property associated with an object. This is accomplished by sending read property commands. To send a read property to the FACP: 1.

  • Page 132: Figure 85 Bacnet Discovery Tool

    Connecting to a BACnet system • The Device Name • The IP Address and UDP Port number • The MS-TP Network number and MAC Address (for some devices) Figure 85 BACnet Discovery Tool Double click any discovered device to see a list of objects contained in that device. The Device name will appear at the top of the objects list and can be double clicked to display the Device Objects Properties window with more detailed information on the device.

  • Page 133: Using The Web Server

    18.0 Using the Web Server The MMX Web Server allows remote monitoring from any computer on the same network as the Fire Alarm Control Panel. The Web Server displays much of the same information that appears on any annunciator connected to the Fire Alarm Control Panel. 18.1 Setting up the Web Server You must purchase a Web Server license in order to use the Web Server.

  • Page 134: Figure 86 Web Services

    Using the Web Server The Network Node Info appears on the right. Figure 86 Web Services 4. Type the static IP address, subnet mask and default gateway. Each node on the TCP/IP network requires its own IP (Internet Protocol) address. The IP address must be unique to the node and it must not be used by any other device on the TCP/IP network.

  • Page 135: Pinging The Fire Alarm Control Panel

    Using the Web Server 18.1.3 Pinging the Fire Alarm Control Panel Before attempting to access the Web Server, ensure that there is a network connection between the computer and the Fire Alarm Control Panel. To ping the Fire Alarm Control Panel 1.

  • Page 136: Web Browser Setup

    Using the Web Server 18.1.4 Web Browser Setup Internet Explorer version 6 or later is recommended. You must configure it to not cache web pages. To set up the web browser 1. In the Internet Explorer 6 menu bar, click Tools, then click Internet Options. The Internet Options window appears.

  • Page 137: Queue Status

    Using the Web Server 18.2.1 Queue Status The Display Queue Status page shows the alarm, supervisory, trouble and monitor queues. To browse through these queues, click the corresponding button. To view the Queue Status: • Click Panel Information, and then click Queue Status. Figure 89 Queue Status 18.2.2...

  • Page 138: Configuration Status

    Using the Web Server 18.2.3 Configuration Status The Configuration Status page shows a list of the nodes that comprise the MMX system. The CPUs that are in use have a CPU number beside their associated node. To view the Configuration Status: •...

  • Page 139: Alarm Log

    Using the Web Server 18.2.4 Alarm Log The Alarm Log page displays the list of all Alarms, including network and system restarts. You can save or print this log with the buttons at the top of the page. Note that there is a delay of a few minutes before the logs update.

  • Page 140: Event Log

    Using the Web Server 18.2.5 Event Log The Event Log page displays a list of all events, including troubles and alarms. You can save or print this log with the buttons at the top of the page. Note that there is a delay of a few minutes before the logs update.

  • Page 141: Udp Socket Table

    Using the Web Server 18.2.7 UDP Socket Table The UDP Socket Table page displays a list containing all the BACnet applications currently connecting to the MMX system from remote locations. Each entry after the first represents a unique connection to the Web Server. To view the UDP Socket Table: •...

  • Page 142: Current Level

    Using the Web Server To view the Routing Table: • Click Network Status, and then click ROUTE. Figure 97 Routing Table To view the Device Table: • Click Network Status, and then click DEVICES. Figure 98 Device Table 18.2.9 Current Level The Current Level page monitors individual devices.

  • Page 143: Figure 99 Devices Info

    Using the Web Server • Click Start to begin monitoring. The Device Info window shows the current level readings and the percentage that the current level is at before it reaches alarm level at or beyond 100%. Figure 99 Devices Info...

  • Page 144: Using The Configurator

    19.0 Using the Configurator 19.1 Overview The MGC Fire Detection and Mass Notification Configurator (the Configurator) is an application that lets you create and manage jobs. A job is a set of configuration data that uniquely describes and controls a set of Fire Alarm Control Panel hardware. The Configurator also allows you to send firmware to a panel and all its related nodes and CPUs.

  • Page 145: Major Components Of The Configurator Window

    Using the Configurator The folder where the C output files are stored. Job Build Folder Displays or hides a Tools menu. This menu contains trace Show Tools Menu and debug functions and features that are helpful to Technical Support. If this option is selected, only the latest versions of all jobs Keep Only Latest Versions will be kept after a successful Backup Database After Backup...

  • Page 146: Job Tree

    Using the Configurator When one or more input circuits are selected in the Details pane, then the Correlations pane shows the output circuits they are correlated to. 19.4 Job Tree The Job Tree lists the following items: • Job Details •...

  • Page 147: Job Details

    Using the Configurator 19.5 Job Details This section explains the options in the Job Details. Figure 102 Job Details To see the Job Details • Select the Job Details node (the highest node) in the Job Tree. Job Info The Job Info section shows details of the job's name, number, creation date and author, and any comments.
  • Page 148 Using the Configurator Options Select this check box to configure the system as a two Two stage stage system. If you do not select this, then the system is single stage. As per UL 864 and UL 2572 only a setting of Single Stage (disabled) is permissible.
  • Page 149 Using the Configurator Select this check box to set the system to compensate for Drift compensation drift (buildup of dust in the detectors that can lead to inaccurate readings). As per UL 864 and UL 2572 only a setting of Enable is permissible.
  • Page 150 Using the Configurator Timers On a two stage system, the stage one alarm (alert) will Auto GA change to the stage two alarm (general alarm) after this amount of time. Auto GA must be shorter than Auto Signal Silence. Choose from 0-30 minutes or Disabled. To use this option, you must select Two stage above.
  • Page 151 Using the Configurator This timer is started by the first active alarm. Paging is Page Inhibit inhibited while this timer is running. As per UL 864 and UL 2572 only a setting of 0 is permissible. Choose from 10-120 seconds. If the only trouble is an AC power failure, this is the Powerfail Send Delay amount of time after the power failure that the system...

  • Page 152: Holidays

    Using the Configurator 19.5.1 Holidays During a holiday, the system goes into After Hours mode. You can add and remove holiday definitions. To add a new holiday 1. Click Enable Auto After Hours at the bottom of the Job Details. 2.

  • Page 153: Network Node

    Using the Configurator Make sure that your holidays do not overlap. Note: To change the duration of a holiday By default the holiday has a Duration of 1 day. Change this to specify a longer holiday. • Type 9999-12-25 2 to specify a two day break beginning on December 25th. To remove a holiday •...

  • Page 154: Figure 105 Network Node Details

    Using the Configurator To see the Network Node Details • Select a node in the Job Tree. Figure 105 Network Node Details If you select this check box, the system will use alternate Alternate Ground Fault ground fault detection settings to compensate for the Detection capacitance and resistance of long audio cable runs.

  • Page 155: Node Grouping

    Using the Configurator The IP (Internet Protocol) address of this node's Ethernet IP Address connection. Identifies which network segment the node is on. Subnet mask The address of the local IP router that forwards traffic Default gateway outside of the local network. If you select this check box, then a trouble is reported if no Supervise Ethernet Ethernet cable is connected to the node.

  • Page 156: Base I/O

    Using the Configurator In a combined fire and MNS (Mass Notification System) installation, Node Grouping is used to separate the MNS nodes from the fire nodes. To create a group • Click Add, type a name for the group, and then click OK. To rename a group 1.

  • Page 157: Figure 106 Base I/O

    Using the Configurator Figure 106 Base I/O Select this box to indicate that the Base IO has Style D Style D (Class A) Conv (Class A) conventional inputs. Inputs Select this box to indicate that the Base IO's input Style D (Class A) Input modules' field wiring is Style D (Class A).

  • Page 158: Main Display / Lcd Annunciator

    Using the Configurator Select this box to set the Trouble relay on this node to Common trouble relay activate on node level trouble. follows node trbl Select this box to indicate that the LEDs of the Device LEDs flash when addressable devices on this loop flash when polled.

  • Page 159: Figure 108 Main Display

    Using the Configurator To see the main display or LCD annunciator details • Select a main display or annunciator in the Job Tree. Figure 108 Main Display Options Select this check box to make the system report a trouble Supervise Printer if the printer is disconnected.

  • Page 160: Passcodes

    Using the Configurator System Messages There are three 20 character text fields for the System Normal Message, and three 20 character text fields for the After Hours Message. Locale Select the language for this annunciator. The system uses Language this language for any messages. The Main Display's language is the default language for other annunciators that are added to the job.

  • Page 161: Access Levels

    Using the Configurator • MONITOR: 3 To enter a passcode on the main display 1. Press the queue buttons corresponding to the numbers. For example, to enter the passcode 2222, press the TROUBLE QUEUE button 4 times. 2. Press the ENTER button. 19.8.2 Access Levels Specify the level of access for various panel actions.

  • Page 162: 19.10 Display Adder

    Using the Configurator 19.10 Display Adder To add a display adder 1. Select the annunciator or display adder that you want to add a display adder to. 2. Click Insert > Add Display Adder. The Add Display Adder window appears. Figure 111 Add Display Adder 3.

  • Page 163: 19.11 Udact

    Using the Configurator Table 22 Display Adders (Continued) Name Description Applies only to common control switches. The column displays the Node Group to which the common control operation is to be limited. Global Node Group means that the operation is system wide and is the default. If the user has created Node Groups, then one of those groups can be chosen.

  • Page 164: Figure 112 Add Udact

    Using the Configurator To add a UDACT 1. Select the node that you want to add a UDACT to. 2. Click Insert > Add UDACT. The Add UDACT window appears. Figure 112 Add UDACT 3. Select Contact ID, SIA300 or SIA110 in the Report Format menu. 4.
  • Page 165 Using the Configurator To get the configuration information • Click Get. The Sent/received field will tell you if the configuration is out of date. To automatically assign a UDACT group to every unassigned zone and output circuit • Click Auto-Assign. Account Six digit decimal for the SIA report formats and four digit Account ID...

  • Page 166: 19.12 Adding A Device

    Using the Configurator Dialer Select the number of retries that you want the dialer to Line make. You can program the dialer remotely over a phone line. Rings Select the number of rings before the dialer answers when you call it. Warning: If this is set to zero the next dial-in session will not connect.

  • Page 167: 19.13 Adding A Cosap Device

    Using the Configurator The Add Device window appears. Figure 114 Add Device 3. Select the type of device from the Type menu. 4. Select the subtype of device from the SubType menu. 5. In the Process as menu, select the process type for the device. For example, Alarm Input or Verified Alm for a photoelectric detector.

  • Page 168: 19.14 Adding A Circuit Adder

    Using the Configurator When you add a COSAP device, by default the starting number is S100. This number must match the address physically set on the device’s dials. For example, if device’s physical address is 100, then set the number in the Configurator to S100. Figure 115 Add COSAP device You can change the starting address for advanced protocol devices under Base I/O.

  • Page 169: 19.15 Adding A Loop Controller

    Using the Configurator To add a circuit adder 1. Select the conventional hardwired loop that you want to add a circuit adder to. 2. Click Insert > Add Ckt Adder. The Add circuit adders window appears. Figure 117 Add circuit adders 3.

  • Page 170: Figure 119 Loop Controller

    Using the Configurator 6. Click Add. The Configurator adds the loop controllers. If the number of loop controllers that you selected exceeds the maximum number of loop controllers allowed on this node, an error message appears saying that the Configurator cannot add some of the CPUs.

  • Page 171: 19.16 Correlations

    Using the Configurator 19.16 Correlations Programming a Fire Alarm Control Panel consists of correlating inputs to outputs. For example, you might correlate all the smoke detectors on the first floor to the speakers on the first and second floors, and smoke detectors on the second floor to the speakers on the first, second, and third floors, and so on.

  • Page 172: 19.17 Custom Messages

    Using the Configurator To add a correlation to an item 1. Right-click the item in the Details Pane. 2. Click Add Correlations. The Select items to add window appears. 3. Double-click the correlations that you want to add, and then click Close. Output Circuit Correlations If the selected circuits are outputs, then the Correlations Pane usually has tabs for: •...

  • Page 173: Figure 122 Custom Messages

    Using the Configurator • The devices are correlated with zones, and the zones are correlated with the custom message Exhibit Hall. When any device becomes active, the custom message is displayed on the remote annunciator. Figure 122 Custom Messages The ND (No Display) flag can be set for input message types. When set, no message will be shown on the target CPU's LCD.

  • Page 174: 19.18 Audio Controller

    Using the Configurator The message appears in the Details Pane. To correlate a custom message with an input or output 1. Right-click your custom message, and then click Add Correlations. For input messages, the possible correlations are separated into Alarm, Supervisory, Trouble and Monitor.

  • Page 175: Figure 125 Audio Controller Details

    Using the Configurator To see the Audio Controller Details • Select an audio controller in the Job Tree. Figure 125 Audio Controller Details Type a description for the audio controller. This will appear in the Job Tree. Select the CPU address for the audio controller. CPU Number Select this check box if the amplifier bin arrangement is QMB-5000 in Bin 0...
  • Page 176 Using the Configurator Select this check box if there is a microphone connected Microphone present to this audio controller. If there are two or more microphones, then one must be designated as the master microphone and the Control enable required for mic press to talk check box must be selected on every audio controller with a microphone.

  • Page 177: 19.19 Panel Information

    Using the Configurator 19.19 Panel Information This window displays a summary of panel and the configurator information. To view configuration information from the Configurator 1. In the Configurator, click Panel > Connect. 2. Click Panel > Panel Information. The Panel Information window appears. Figure 126 Panel Information The name of the job that is currently active on the FACP.

  • Page 178: 19.20 Advanced Panel Information

    Using the Configurator 19.20 Advanced Panel Information This window displays detailed information about the panel. To view Advanced Panel Information 1. Click Panel > Connect. 2. Click Panel > Panel Information. 3. Click Advanced. The number assigned to each node. Node The number for each CPU on the node.

  • Page 179: 19.22 Restoring The Database

    Using the Configurator You can change the backup folder in User Preferences. See section 19.2 on page 144. If the Keep Only Latest Versions After Backup option is selected in User Preferences, only the latest versions of all jobs will be kept after a successful Backup Database command. All older versions will be deleted.

  • Page 180: 19.24.1 Advanced Compare Options

    Using the Configurator The Select Job to Compare window appears. Figure 127 Select Job to Compare 3. Select the second job. This is the secondary job. • Select Show Identical Items if you want to see not only changes, but also those items that stayed the same.

  • Page 181: 19.24.2 Interpreting The Results

    Using the Configurator Select this check box to include any item that has been Modified modified (it is the same adder, circuit, or switch but some attribute has been changed). Select this check box to include items that are only Present only in Secondary present in the secondary job.

  • Page 182: 19.24.3 Printing The Comparison

    Using the Configurator A magnifying glass indicates items that have been modified. Click the item to see the change. A green check mark indicates items that are the same. If you unselect Modified in the Advanced Compare Options, then a green check mark appears next to items that have been modified, but that have no deletions or additions.

  • Page 183: 19.24.4 How Does The Configurator Decide What Is Added, Removed, Or Changed

    Using the Configurator If the print range of the job is Complete Job, then you may decide to choose only one of Input or Output Correlations, since every input has a corresponding output somewhere on the job. If the print range of the job is not Complete Job, then selecting only Input or Output might not include all the correlations.

  • Page 184: 19.25 Creating A Job

    Using the Configurator 19.25 Creating a Job To create a job 1. Click Job > New Job. The Create Job window appears. Figure 132 Create Job 2. Type a name for the job in the first field. This name should be unique. It will identify the job throughout its lifetime.

  • Page 185: 19.26 Opening A Job

    Using the Configurator 19.26 Opening a Job To open a job 1. Click Job > Open Job. The Select Job and Version window appears. Figure 133 Select Job and Version This window shows all the jobs in the database. 2. Click on the column heading to sort the jobs by: •...

  • Page 186: 19.28 Display Structure

    Using the Configurator 19.28 Display Structure The Display Structure feature lets you view the contents of a panel data structure. To display a structure 1. Connect to the panel. 2. Click Tools > Display Structure. If you do not see the Tools menu, you must enable it. See section 19.2 on page 144. The Display Firmware Data Structure window appears.

  • Page 187: 19.29.1 Editing A Job

    Using the Configurator 19.29.1 Editing a job When you open a job, whether by getting it from the panel or opening it from the database, it is locked by default, and you must unlock it in order to edit it. To edit a job •...

  • Page 188: 19.30 Paste Special

    Using the Configurator To create a new version of a job 1. Click Job > New Version. The New Job Version Information window appears. Figure 137 New Job Version Information 2. Type a comment in the Comments field. This is required. 3.

  • Page 189: 19.31 Print

    Using the Configurator You can use Paste Special to paste display items, display adders, or annunciators. Figure 139 Paste Special for annunciators Select the number of copies to make. Number of copies Click this button to make an unrelated copy of the source. Make new copy Select this check box if you want the copied devices to Copy correlations...

  • Page 190: Figure 140 Print

    Using the Configurator The Print window appears. Figure 140 Print Prints the complete job, and prints each major item of the Complete Job Job Tree on a new page. Prints only the currently selected item. No details of Current Item contained loops are printed.

  • Page 191: 19.32 Security Key Logon

    Using the Configurator 19.32 Security Key Logon This window appears if the CodeMeter key is inserted when you start the Configurator. It also appears if the key is inserted later. Figure 141 Security Key Logon • Type your PIN and click OK. 19.33 Upgrade Firmware This window appears when you select the Upgrade Firmware command, after you have selected a firmware archive.

  • Page 192: 19.34 Update Panel Time

    Using the Configurator 19.34 Update Panel Time To update the panel time 1. Click Panel > Panel Information. The Panel Information window appears. See section 19.19 on page 177. 2. Click Update. The Update Panel Time window appears. Figure 143 Update Panel Time 3.

  • Page 193: 19.36 System/Node/Cpu Status

    Using the Configurator The technician who created the version. Changed by The description that was entered when the new job Description version was created. Uploaded: The new job version was a result of a Get Type • Job. New Job: The user created a new version manually. •...

  • Page 194: Figure 145 System Status

    Using the Configurator The Scope column specifies the Node and CPU of the status. You must have defined a suitable LED to accept the correlation from the Node or Node/CPU specific status. Figure 145 System Status Table 23 describes the columns in the System Status view. Table 23 System Status Name Description...

  • Page 195: Table 24 Customer Intervals

    Using the Configurator 19.37 Custom Intervals A custom interval is a period of time during the day. Intervals have a start time, an end time, and an optional day of the week. If the day of the week is not specified, then the interval applies every day.

  • Page 196: Table 25 Customer Timers

    Using the Configurator As per UL 864 and UL 2572 only a setting of un-assigned is permissible. Note: To view custom timers • Select Custom Timers in the Job Tree. To create a timer • Double-click in the Enable column, and then click Y in the menu. You can use custom timers in equations.

  • Page 197: Figure 146 Led Annunciator

    Using the Configurator Table 26 Input Zones (Continued) Name Description Type Double-click in this column to change the process type of the zone. Specifies the priority given to digitized messages correlated to this input zone: -95% (lowest) through Normal (default) to +95% (Highest). Activation of a zone with a higher priority will cause its message to be played, and any lower priority message will cease to play.

  • Page 198: Table 27 Loop Details

    Using the Configurator • Double-click in the CPU column to change the CPU address. • Double-click in the Tag column to change the tag. 19.42 Loop Details The loop details displays the hard wired (conventional) circuits or addressable devices in a loop.
  • Page 199 Using the Configurator Table 27 Loop Details (Continued) Name Description The description, in two 20 character fields, that appears on the panel when Tag1 and 2 an alarm occurs. Alternate The description that appears on displays where Alternate Tags is Tag (Line 1 selected.
  • Page 200 Using the Configurator • Alarm 5: Level 5 - 3%/ft of smoke. Time elapsed from smoke detection is • Alarm 6: Level 6 - Heat only alarm. If the heat level on either thermistor exceeds 1 limits. • CO Operation: CO only alarm. 19.43 Fire Phone Configuration You can set up an audio controller, conventional phones, voice lines, remote field phones, master telephone handsets and telephone selectors, and you can connect them together.

  • Page 201: Figure 147 Add Device

    Using the Configurator 19.43.2 Adding a fire phone module To add a fire phone module 1. Select the loop that you want to add a device to. 2. Click Insert > Add Device. The Add Device window appears. Figure 147 Add Device 3.
  • Page 202 Using the Configurator To add a telephone/page selector 1. Select the annunciator or display adder that you want to add the telephone to. 2. Click Insert > Add Display Adder. 3. Select Telephone/Page Selector in the Select Adder Type pulldown menu. 4.
  • Page 203 Using the Configurator 19.43.6 A fire phone device cannot be copied if it is already correlated to a selector switch A fire phone device cannot be copied if it is already correlated to a selector switch. If you attempt to copy such a device (or a loop that contains one) an error message appears. If you need to copy phones, use Paste Special and unselect Copy display correlations.

  • Page 204: Figure 148 Make A Switch A Phone Selector Switch

    Using the Configurator 4. Press switch number 1 on node 3 to answer the call from node 2. Node 2 and node 3 turn off their buzzers and the green LEDs turn solid. The operators at all 3 nodes can now talk to each other. 5.

  • Page 205: Figure 149 Add Correlations To A Phone Selector Switch

    Using the Configurator 3. For switch number 1, double-click <unassigned> and select Phone Sel. 4. Repeat steps 1 and 2 for nodes 2 and 3. Correlate the phone selector switches across nodes 1. Select the Telephone/Page Selector under node 1’s Main Display. 2.

  • Page 206: Figure 151 Add Correlations To A Phone Selector Switch

    Using the Configurator Figure 151 shows that switch number 1 on node 3 is available for correlation. Figure 151 Add Correlations to a Phone Selector Switch 13. Select switch number 1 for Node 3, and then click Add. 14. Click Close. The switches are now correlated as follows: •...
  • Page 207 Using the Configurator • (c) after a period of not more than 10 min., the silenced audible signal devices will be restored to continuous audible signal if the alarm is not acknowledged... 19.45.1 Timers for Suite Silence There are three timers for suite silence in the Job Details. See section 19.5 on page 147. •...

  • Page 208: Figure 152 Timers For Suite Silence

    Using the Configurator 19.46 Configuring suite silence To configure suite silence 1. Select Job Details in the job tree. 2. Set the Alert rate to Alert and the Evac rate to Temporal. 3. If the job has audio, click the Set up button under Audio. Click the buttons beside Alert and Evac and set the alert rate to Alert and the Evac rate to Temporal.

  • Page 209: Table 28 File Menu

    Using the Configurator 19.47 Menus 19.47.1 File Menu The File menu contains the following commands: Table 28 File Menu Name Short cut Description Backup database makes a copy of the Master Database in the File folder specified in the User Preferences. The backup file will have a name of the form YYYY-MM- DD.mdb.

  • Page 210: Table 30 Insert Menu

    Using the Configurator Table 29 Job Menu (Continued) Name Short cut Description Imports a selected job/version from an external database or Import Job serialized job archive and converts the job to the current version if necessary. Exports the current job in one of two formats: A single job Export Job Ctrl+E database file, or a compact, serialized archive format.

  • Page 211: Table 31 Edit Menu

    Using the Configurator Table 30 Insert Menu (Continued) Name Description Add Display Add a Display Adder to an Annunciator or Base Panel. Adder Add UDACT Add UDACT capability to the selected network node. Add Audio Add an Audio Controller to the selected network node. A maximum of one Controller Audio Controller is allowed per node.

  • Page 212: Table 33 Tools Menu

    Using the Configurator Table 32 Panel Menu (Continued) Name Short cut Description Get the job from the panel and store it on the configuration Get Job Ctrl+G tool's database. The job becomes the current job, shown in the user interface. Displays the jobs currently loaded on the panel and lets you Manage Jobs delete them.
  • Page 213 Using the Configurator Table 33 Tools Menu (Continued) Name Short cut Description Toggles the "Use External Bus" setting. When turned on, External Bus this signals that the configurator is connected to the External Bus of the panel. Note: The Tools menu is only available if you checked the Show Tools Menu option. See User Preferences.
  • Page 214 List of Procedures To connect the computer to the Fire Alarm Control Panel ..............17 To send a job ............................18 To get the current active job from the Fire Alarm Control Panel ............19 To export the job as a database file or an XML file ................20 To manage jobs on the panel ......................20 To change the active job using the Fire Alarm Control Panel ............21 To change the active job using the Configurator ................22...
  • Page 215 List of Procedures To correlate the zone with an output ....................64 To create a custom interval ......................64 To create a zone latching sequence ....................67 To create a relay pulsing sequence ....................68 To calculate the maximum recommended length of a cable ............98 To turn on Alternate Ground Fault Detection ..................101 To connect the TNC-5000 telephone bus terminals with shielded wiring .........103 To connect the M500 addressable modules with shielded wiring .............103...
  • Page 216 List of Procedures To add a display adder ........................162 To view the display adder .........................162 To add a UDACT ..........................164 To view the dialer ..........................164 To get the configuration information ....................165 To automatically assign a UDACT group to every unassigned zone and output circuit ....165 To configure the dialer with the Configurator ..................166 To add a device ..........................166 To add a circuit adder ........................169...
  • Page 217 TECHNICAL SUPPORT U.S.A CANADA - Main Office © Secutron 2016 4575 Witmer Industrial Estates 25 Interchange Way North America Printed in Canada Subject to change without prior notice Tel: (905)-695-3545 Niagara Falls, NY 14305 Tel: Vaughan, ON L4K 5W3 Tel: (888) 732-8876...

This manual is also suitable for:

Mmx-2003-12ndsMmx-2003-12nxtdsMmx-2009-12ndsMmx-2017-12ndsMmx-2000mns

Table of Contents
