LCD Fire Alarm Control Panel
LT-954SEC Rev. 1
User Guide
February 2017

Advertisement

Table of Contents
loading

Related Manuals for Secutron MR-2300 Series

Summary of Contents for Secutron MR-2300 Series

  • Page 1 MR-2300 Series LCD Fire Alarm Control Panel LT-954SEC Rev. 1 User Guide February 2017...

  • Page 3: Table Of Contents

    Table of Contents Introduction About this Manual ......................Technical Support ......................Main Display The Buzzer and LED Indicators Buzzer ..........................A.C. On LED ........................Alarm LED ........................Supervisory LED ......................Trouble LED ........................CPU Fail LED ......................... Main Display Buttons SYSTEM RESET ......................
  • Page 4 List of Figures Figure 1 Main Display ........................Figure 2 LED Indicators ........................ Figure 3 Verified Alarm Example ....................Figure 4 Silenceable Signal Example ................... Figure 5 AC Power Fail ........................ Figure 6 Battery Trouble ....................... Figure 7 Ground Fault ........................Figure 8 RAU num mismatch .......................

  • Page 5: Introduction

    Refer to the Glossary on page 18 for an explanation of commonly used terms in this manual. Technical Support For all technical support inquiries, please contact MGC’s Technical Support Department between 8 A.M. and 5 P.M. (EDT) Monday through Friday, excluding holidays. Toll-Free Phone: 1-888-SECUTRON (1-888-732-8876) Local Fax: 905-660-4113 Toll-Free Fax: 1-888-660-4113 5 (20)

  • Page 6: Main Display

    Main Display Figure 1 shows the LCD display, LED indicators, and control buttons locations. SYSTEM NORMAL 18:01 MON 2003-04-05 A .C. O N ALARM S UPV TRBL CPU FAIL SYSTEM RESET SIG N AL EN TER SIL EN CE FIRE MEN U D RIL L G HI...

  • Page 7: The Buzzer And Led Indicators

    The Buzzer and LED Indicators A.C. ON ALARM SUPV TRBL CPU FAIL Figure 2 LED Indicators Buzzer The buzzer sounds if there is a fire alarm, a supervisory alarm, or a trouble in the fire alarm system. It turns off if the condition causing the buzzer to sound is cleared or if the BUZZER SILENCE button is pressed.

  • Page 8: Main Display Buttons

    Main Display Buttons SYSTEM RESET The SYSTEM RESET button resets the fire alarm control panel and all SYSTEM circuits. RESET SIGNAL SILENCE Pressing the SIGNAL SILENCE button when the panel is in alarm deactivates any silenceable signal devices in the fire alarm system. Non-silenceable signal devices are unaffected.

  • Page 9: The Up And Down Arrow Buttons

    Main Display Buttons The Up and Down Arrow Buttons Use these buttons to scroll through any events listed on the screen. The up arrow moves to the next listed condition and the down arrow moves to the previously listed condition. INFO Press the INFO button while the there is a message on the screen to view INFO...

  • Page 10: Disconnecting And Reconnecting A Circuit (Zone)

    Disconnecting and Reconnecting a Circuit (Zone) You can disconnect and reconnect detection and signal circuits (zones) from the panel using the bypass options in the menu. To select the bypass options, you must be in the Command Menu. To enter the Command Menu, press MENU To Disconnect (Bypass) a Circuit...
  • Page 11 Disconnecting and Reconnecting a Circuit (Zone) To Reconnect (Unbypass) a Circuit Step 1: Enter your passcode 1. Press MENU. Enter the 2. Enter your passcode. passcode 3. Press ENTER. ENTER Step 2: Select the Bypass menu 1. Use the up and down arrow buttons to scroll down to “Bypass Det Ckt”...

  • Page 12: Understanding On-Screen Messages

    Understanding On-screen Messages The screen of the fire alarm control panel displays messages regarding system events. System events display on the screen in a queue. Events in this queue are listed on the screen in order of priority: alarms are of highest priority, followed by supervisory, trouble, and monitor conditions.

  • Page 13: Example 2 (Indicating Circuit)

    Understanding On-screen Messages Example 2 (indicating circuit): Figure 4 indicates that event 2 of 9 is a short trouble at the East Wing Lobby. When INFO pressed, the screen shows that the process type is silenceable on NAC-1 and the event occurred on Tuesday February 2, 2003 at 18:01.

  • Page 14: Figure 6 Battery Trouble

    Understanding On-screen Messages 6.3.2 Battery Trouble The “Battery Trouble” message indicates that the battery voltage has dropped below the minimum value. The trouble is restored when the voltage returns to the normal value. T ro u b le co d e T ro u b le In fo T ro u b le T yp e B a t t e r y T r o u b l e...

  • Page 15: Figure 9 4Wire Pwr. Supply

    Understanding On-screen Messages T ro u b le in fo T ro u b le T yp e T ro u b le c o d e R A U n u m m i s m a t c h T r b : 0 x 0 3 I n f o : 0 x 0 0 0 1 "IN F O "...

  • Page 16: Figure 10 Aux. Power Supply

    Understanding On-screen Messages T ro u b le co d e T ro u b le In fo T ro u b le T yp e A u x . P o w e r S u p p l y T r b : 0 x 0 3 I n f o : 0 x 0 0 0 1 "I N F O "...

  • Page 17: Figure 12 City Tie Trouble

    Understanding On-screen Messages T ro u b le c o d e T ro u b le In fo T ro u b le T yp e C i t y T i e t r o u b l e T r b : 0 x 0 3 I n f o : 0 x 0 0 0 1 "IN F O "...

  • Page 18: Glossary

    Glossary Alarm Condition Occurs when devices such as detectors, pull stations, or sprinklers are activated. In a single stage system, this condition activates all signalling devices throughout the building. In a two stage system, this condition activates an alert signal and the General Alarm timer. Circuits Refers to an actual electrical interface and is classified as initiating (detection), indicating (signal), or relay.
  • Page 19 Glossary Relay Circuit A circuit in a fire alarm system that connects relay devices (for example, fan damper relays). Remote Annunciator A device that visually indicates, either by LCD or LEDs, the floor or zone where the alarm originated. Silenceable Circuit A signal circuit that can be silenced by pressing the SIGNAL SILENCE button.
