Maintenance
9.2
Maintenance tasks
9.2.1
Cleaning the sensor
Removing sensor from assembly
Remove sensor from assembly CCA151
1.
Unscrew union nut from assembly.
1
Disinfection sensor CCS50D
2
Flowfit CCA151 flow assembly
3
Union nut for securing a disinfection sensor CCS50D
2.
Pull sensor out through opening in assembly.
Remove sensor from assembly CCA250
1.
Remove adapter studs used to secure the adapter to the sensor.
2.
Carefully remove adapter in the direction of the sensor head.
3.
For detailed information on "Removing sensor from assembly CCA250", see Operating
Instructions for assembly.
Remove sensor from assembly CYA112
1.
Remove adapter studs used to secure the adapter to the sensor.
2.
Carefully remove adapter in the direction of the sensor head.
3.
For detailed information on "Removing sensor from assembly CYA112", see Operating
Instructions for assembly.
32
3
2
CCS50D
1
Endress+Hauser
A0034261
