Example of a measuring system
1
Liquiline CM44x transmitter
2
Power cable for transmitter
3
Disinfection sensor CCS50D (membrane-covered, ⌀25 mm)
4
Outlet from Flowfit CCA151 flow assembly
5
Inlet to Flowfit CCA151 flow assembly
6
Flowfit CCA151 flow assembly
7
Union nut for installing a disinfection sensor in the Flowfit CCA151 flow assembly
8
Measuring cable CYK10
18
CCS50D
1
2
3
4
5
A0034241
