- Page 1 Products Solutions Services BA00058C/07/EN/14.18 71423117 2018-10-23 Operating Instructions CCS140/141 Sensors for measuring free available chlorine...
-
Page 3: Table Of Contents
CCS140/141 Table of contents Table of contents About this document ... 4 Accessories ....33 Warnings . -
Page 4: About This Document
About this document CCS140/141 About this document Warnings Structure of information Meaning This symbol alerts you to a dangerous situation. DANGER Failure to avoid the dangerous situation will result in a fatal or serious injury. Causes (/consequences) If necessary, Consequences of non- compliance (if applicable) ‣... - Page 5 CCS140/141 About this document 1.2.1 Symbols on the device Symbol Meaning Reference to device documentation Endress+Hauser...
-
Page 6: Basic Safety Instructions
Basic safety instructions CCS140/141 Basic safety instructions Requirements for the personnel Installation, commissioning, operation and maintenance of the measuring system may be carried out only by specially trained technical personnel. ‣ The technical personnel must be authorized by the plant operator to carry out the specified activities. -
Page 7: Product Safety
CCS140/141 Product description Ensure that electrical cables and hose connections are undamaged. Do not operate damaged products, and protect them against unintentional operation. Label damaged products as defective. During operation: ‣ If faults cannot be rectified: products must be taken out of service and protected against unintentional operation. - Page 8 Product description CCS140/141 Fixed cable Sensor shaft O-ring Large anode, silver/silver chloride Gold cathode Measuring chamber Membrane cap with dirt-repellent membrane Screw cap for securing the membrane cap A0037109 3.1.1 Measuring principle Free available chlorine levels are determined using hypochlorous acid (HOCl) in accordance with the amperometric measuring principle.
- Page 9 CCS140/141 Product description As hypochlorous acid splits up (dissociates) with an increasing pH value to form hypochlorite ions (OCl – ) and hydrogen ions (H ), the amounts of the individual components of free effective chlorine change with the pH value. For example, if the proportion of hypochlorous acid is 97 % at pH 6, it drops to approx.
- Page 10 Product description CCS140/141 the sensor at the same pH value with respect to the calibration. Without pH compensation, the chlorine measuring system must be recalibrated when the pH value changes. 10 11 A0002017 1 Principle of pH compensation Measured value with pH compensation...
- Page 11 CCS140/141 Product description the actual value of the free chlorine. Calibration of the entire measuring system is practicable only if the medium has a pH value of 8 (CCS140) or pH value of 8.2 (CCS141). Sensor pH value HOCl content...
-
Page 12: Incoming Acceptance And Product Identification
Incoming acceptance and product identification CCS140/141 Incoming acceptance and product identification Incoming acceptance Verify that the packaging is undamaged. Notify the supplier of any damage to the packaging. Keep the damaged packaging until the issue has been resolved. Verify that the contents are undamaged. - Page 13 A new window (Device Viewer) opens. All of the information relating to your device is displayed in this window as well as the product documentation. 4.2.4 Manufacturer address Endress+Hauser Conducta GmbH+Co. KG Dieselstraße 24 D-70839 Gerlingen 4.2.5 Scope of delivery The delivery comprises: •...
-
Page 14: Installation
Installation CCS140/141 Installation Installation conditions 5.1.1 Installation position 5.1.2 Dimensions Ø12 (0.47) Ø 36 (1.42) Ø 29 (1.14) Ø 25 (0.98) A0037111 2 Dimensions in mm (in) Version with TOP68 plug-in head Version with fixed cable connection Endress+Hauser... -
Page 15: Mounting The Sensor
REL 2 A0037473 3 Example of a measuring system Flowfit CCA250 flow assembly Inlet to Flowfit CCA250 flow assembly Proximity switch (optional) pH sensor CPS31 PML pin Chlorine sensor CCS140 Procedure Sampling tap Measuring cable CPK9 Liquisys CCM223/253 transmitter Endress+Hauser... - Page 16 Installation CCS140/141 ‣ Ground the medium at the sensor by means of the PML pin to ensure a high reading stability. 5.2.2 Preparing the sensor Removing protection cap from sensor NOTICE Negative pressure causes damage to the sensor's membrane cap.
-
Page 17: Post-Installation Check
CCS140/141 Electrical connection 5.2.3 Installing sensor in assembly CCA250 The Flowfit CCA250 flow assembly is designed for installing the sensor. It allows a pH and ORP sensor to be installed, in addition to the chlorine or chlorine dioxide sensor. A needle valve controls the flow rate in the range of 30 to 120 l/h (7.9 to 31.7 gal/h). -
Page 18: Connecting The Sensor
Electrical connection CCS140/141 Connecting the sensor ‣ Install the grounding bar (order number 51501086) in accordance with the accompanying instructions in order to guarantee a high reading stability. NOTICE Measured errors due to faulty connection ‣ When connecting the sensor cable, make sure that the black semi-conductor layer is removed as far as the inner shield. - Page 19 CCS140/141 Electrical connection A0037112 7 Sensor with TOP68 plug-in head and CPK9 measuring cable with internal PAL (CPK9-N*A1B) Signal (cathode) (black coax) Reference (anode) (screened coax) Not used (white) Temperature sensor (green) Temperature sensor (yellow) Not used (brown) 6.1.1 Connecting the cable extension To extend the sensor connection, use the VBC junction box.
-
Page 20: Ensuring The Degree Of Protection
Electrical connection CCS140/141 7.2 (0.28) ±0.1 A0037106 9 Structure of measuring cable CYK71, specifications in mm (in) Coax, e.g. pH, ORP Shielding 4 control lines YE/GN/WH/BN Ensuring the degree of protection Only the mechanical and electrical connections which are described in these instructions and which are necessary for the required, designated use, may be carried out on the device delivered. -
Page 21: Commissioning
CCS140/141 Commissioning Commissioning Function check Prior to initial commissioning, ensure that: • The sensor is correctly installed • The electrical connection is correct. • There is sufficient electrolyte in the membrane cap and the transmitter is not displaying a warning about electrolyte depletion. - Page 22 Commissioning CCS140/141 Requirements The sensor reading is stable (no drifts or unsteady values for at least 5 minutes). This is normally guaranteed once the following preconditions have been met: • The polarization period has elapsed. • The flow is constant and within the correct range.
-
Page 23: Diagnostics And Troubleshooting
CCS140/141 Diagnostics and troubleshooting Diagnostics and troubleshooting When troubleshooting, you must take account of the entire measuring system. This comprises: • Transmitter • Electrical connections and lines • Assembly • Sensor The possible causes of error in the following table refer primarily to the sensor. Before commencing troubleshooting, ensure that the following operating conditions have been met: •... - Page 24 Diagnostics and troubleshooting CCS140/141 Error Possible cause Remedy ‣ Display value too low Measuring chamber not Fully tighten measuring chamber or screw cap completely tightened ‣ Membrane soiled Clean membrane ‣ Air bubble in front of membrane Release air bubble ‣...
-
Page 25: Maintenance
CCS140/141 Maintenance Maintenance Please note the information on the safety data sheet to ensure safe use of the electrolyte. Take all the necessary precautions in time to ensure the operational safety and reliability of the entire measuring system. NOTICE Effects on process and process control! ‣... - Page 26 Maintenance CCS140/141 9.2.2 Replacing the membrane A0037110 10 Replacing the membrane Measuring chamber Membrane cap Screw cap Unscrew the measuring chamber (1). Unscrew the front screw cap (3). Remove the membrane cap (2) and replace it with a CCY14-WP replacement cartridge.
- Page 27 CCS140/141 Maintenance 9.2.3 Refilling the electrolyte NOTICE Damage to membrane and electrodes, air bubbles Possibility of measured errors to complete failure of the measuring point ‣ Do not touch the membrane or electrodes. Avoid damaging them. ‣ The electrolyte is chemically neutral and is not hazardous to health. Nonetheless, do not swallow it and avoid contact with eyes.
- Page 28 Maintenance CCS140/141 For recommissioning, follow the same procedure as for commissioning → 21. Ensure that no biofouling occurs during longer interruptions to measurement. Remove continuous organic deposits such as films of bacteria. Fit protection cap on sensor. To keep the membrane moist after the sensor has been removed, refill the protection cap with electrolyte or clean water.
- Page 29 CCS140/141 Maintenance 9.2.5 Regenerating the sensor During measurement, the electrolyte in the sensor is gradually exhausted due to chemical reactions. The gray-brown silver chloride layer that is applied to the anode at the factory continues to grow during sensor operation. However, this has no effect on the reaction taking place at the cathode.
- Page 30 Maintenance CCS140/141 A0037414 Sensor Gaseous phase of chlorine bleach lye Chlorine bleach lye Distance between sensor and liquid, 5 to 10 mm (0.2 to 0.4 in) Close the medium inlet and outlet and make sure that no medium can escape from the assembly.
- Page 31 CCS140/141 Maintenance If the value of several hundred nA is not reached: Cover the beaker to avoid a rapid exchange of air. 10. Once the 20 minutes have elapsed, re-install the sensor in the assembly. 11. Open the medium inlet and outlet again.
-
Page 32: Repair
The product must be returned if repairs or a factory calibration are required, or if the wrong product was ordered or delivered. As an ISO-certified company and also due to legal regulations, Endress+Hauser is obliged to follow certain procedures when handling any returned products that have been in contact with medium. -
Page 33: Accessories
• Terminated measuring cable for connecting analog sensors with TOP68 plug-in head • Selection in accordance with product structure • Ordering information: Endress+Hauser sales office or www.endress.com. MK extension cable • Twin-core signal cable with additional shielding and PVC insulation •... -
Page 34: Technical Data
• Product Configurator on the product page: www.endress.com/coy8 Technical Information TI01244C Service kit CCS14x • For chlorine sensors CCS140 / CCS141 / CCS142D • 2 replacement cartridges, electrolyte 50 ml (1.69 fl.oz), sanding sheets • Order No. 71076921 Polishing sheet COY31-PF •... - Page 35 CCS140/141 Technical data 12.1.3 Signal current CCS140-* Approx. 25 nA per mg/l Cl (at 25 °C (77 °F), pH 7.2) CCS141-* Approx. 80 nA per mg/l Cl (at 25 °C (77 °F), pH 7.2) Endress+Hauser...
-
Page 36: Performance Characteristics
Technical data CCS140/141 12.2 Performance characteristics 12.2.1 Reference operating conditions 25 °C (77 °F) pH 7.2 12.2.2 Response time < 2 minutes in applications involving mainly active chlorination 12.2.3 Long-term drift < 1.5 % per month 12.2.4 Polarization time Initial commissioning... -
Page 37: Mechanical Construction
CCS140/141 Technical data 12.4.3 pH range At average medium concentrations of 1 mg/l (ppm) Cl and under reference conditions Calibration CCS140-* pH 4 to 8 CCS141-* pH 4 to 8.2 Measurement pH 4 to 9 Chlorine measurement possible up to pH 9 with limited accuracy 12.4.4... -
Page 38: Index
Index CCS140/141 Index Sensor ..... 15 Installation position ....14 Accessories . - Page 39 CCS140/141 Index Sensor Calibration ....21 Cleaning ....25 Connecting .
- Page 40 *71423117* 71423117 www.addresses.endress.com...
