AC switch performance improvements

You can improve AC switch performance in several ways, such as adding a snubber, a R
following table summarizes the configurations.
AC switch
X101
X102
X103
The following tips can help improve the behavior for each AC switch reference.
1. X101 Triac
X101 is a snuberless Triac; it doesn't need a snubber to improve commutation performance. You should add
a varistor to protect the Triac against overvoltage: varistor reference depends on the applied voltage level.
You can also add a R
A (or 4 kV criteria B) levels are required.
2. X102 AC switch
X102 is an overvoltage protected AC switch; it does not need a varistor to protect it against overvoltage. You
can add a snubber to improve commutation performance. You can also modify the R
a snubber to improve dV/dt robustness and therefore IEC61000-4-4 if higher levels are required.
3. X103 AC switch
X103 is an overvoltage protected AC switch; it does not need a varistor to protect it against overvoltage. You
can add a snubber to improve commutation performance. You can also modify the R
a snubber to improve dV/dt robustness and therefore IEC61000-4-4 if higher levels are required.
