STEVAL-GLA001V1 power losses

STEVAL-GLA001V1
connected to the mains voltage and to the secondary side power supply, including:
• ZVS circuit
• LED circuit (high voltage presence)
• MODE switch circuit
• Power supply regulation circuit (secondary)
• LED circuit (VDD voltage)
Standby power losses measurement has been performed using a power meter under the following conditions:
• Vmains = 240 Vrms / 60 Hz
• Tamb = 22 °C
• VDD = 5 V (worst case)
• MODE switch in On/off position (worst case)
240 V / 60 Hz
UM2304 - Rev 3
evaluation board generates limited standby power losses due to the components directly
Table 9. Typical STEVAL-GLA001V1 standby losses
Vmains I(input)
10 mA
UM2304
STEVAL-GLA001V1 power losses
P(input)
288 mW
