Performance; Ac Switch Load Capability; Table 1. Load Capability Versus Ambient Temperature And Ac Switch; Figure 3. Loads Connection Versus Ac Switches - STMicroelectronics STEVAL-GLA001V1 User Manual

1.6

Performance

The STEVAL-GLA001V1
• Stand-by losses < 300 mW (@ 240 V)
• IEC 61000-4-4 (STEVAL-GLA001V1 evaluation board with
– 2 kV criteria A
– 4 kV criteria B
1.7

AC switch load capability

The STEVAL-GLA001V1
Ambient temperature
Load 1
Load 2
Load 3
Total loads power
All of the above values are RMS, for V
switch junction temperature.
Load numbers are given with reference to the following figure.
UM2304 - Rev 3
evaluation board performance characteristics include:
evaluation board is designed to operate with the following load conditions:
Table 1. Load capability versus ambient temperature and AC switch
0 °C
7.2 A = 1650 W
1.5 A = 350 W
0.9 A = 200 W
2200 W
= 230 V
MAINS
Figure 3. Loads connection versus AC switches
NUCLEO-F030R8
25 °C
6.2 A = 1430 W
1.3 A = 300 W
0.75 A = 170 W
1900 W
and with 5% tolerance on the maximum allowed AC
RMS
UM2304
Performance
development board):
60 °C
4.6 A = 1050 W
0.9 A = 205 W
0.5 A = 115 W
1370 W
page 4/46
