1

Getting started

1.1

Overview

The X-NUCLEO-OUT08A1
switch (IPS), is designed to meet the application requirement in terms of galvanic isolation between user interface
(or logic side) and power interface (or process side).
This requirement is satisfied by an optical isolation implemented through two couples of optocouplers:
1. The first couple includes:
a. ISO1: for signal forwarding to the device
and
b. ISO2: for diagnostic signal (DIAG pin) feedback
2. The second couple incudes:
a. ISO3: for the additional output voltage feedback signal
and
b. ISO4: for the additional circuitry driving Q1 to allow fast discharge of the output rail
The main features of the
• Based on
– Operation up to 60 V/2.4 A
– Low power dissipation (R
– Fast decay for inductive loads
– Open load detection and diagnostics
– Overload and overheating protections with thermal shut-down and cut-off
– PowerSSO-12L package
• Application board operating range: 12 to 33 V/0 to 2.4 A
• Extended voltage operating range (J1 open) up to 60 V
• Status and diagnostic LEDs
• 3 kV galvanic isolation
• Supply rail reverse polarity protection
• Ready for Safety Digital Output Architecture
• EMC compliance with IEC61000-4-2, IEC61000-4-3, IEC61000-4-5
• Wide application development potential in
• Equipped with Arduino™ UNO R3 connectors
• CE certified
• RoHS and China RoHS compliant
1.1.1

Digital section

The digital section is associated with the STM32 interface and digital supply voltage to and from the
OUT08A1 expansion board.
The digital and power sections are isolated by 3.3 mm creepage. Communication between the two sections is
guaranteed by ISO1, ISO2, ISO3 and ISO4 optocouplers.
UM2715 - Rev 1
industrial digital output expansion board, embedding the
X-NUCLEO-OUT08A1
IPS160HF single high-side switch, which features:
ON(MAX)
expansion board are:
= 120 mΩ)
STM32 Nucleo development environment
UM2715
Getting started
IPS160HF intelligent power
X-NUCLEO-
page 2/15
