Getting started with X-NUCLEO-OUT05A1 industrial digital output expansion
Introduction
The
X-NUCLEO-OUT05A1
industrial digital output expansion board for
environment for the evaluation of the driving and diagnostic capabilities of the
state relay, in a digital output module connected to 2.5 A industrial loads.
The
X-NUCLEO-OUT05A1
interfaces with the microcontroller on the
and Arduino R3 connectors.
The expansion board can be connected to either a
It is also possible to evaluate a system composed of up to four stacked
As an example, a system with four
output module.
RELATED LINKS
For further details on configuration resistors, refer to UM2864
UM2865 - Rev 1 - March 2022
For further information contact your local STMicroelectronics sales office.
NUCLEO-F401RE
X-NUCLEO-OUT05A1
expansion boards allows you to evaluate a quad channel digital
Figure 1.
X-NUCLEO-OUT05A1 expansion board
