ST X-NUCLEO-OUT07A1 User Manual

Getting started with the X-NUCLEO-OUT07A1 industrial digital output expansion
Introduction
The X-NUCLEO-OUT07A1 is an industrial quad digital output expansion board for STM32Nucleo. It provides a powerful and
flexible environment for the evaluation of the driving and diagnostic capabilities of the
solid-state relay in a digital output module connected to four 0.7 A industrial loads. The system is also designed to facilitate the
user to configure the application as a dual digital output module for 1.0A industrial loads, or as a single digital output module for
2.0A industrial loads.
The X-NUCLEO-OUT07A1 interfaces with the microcontroller on the
isolators, and via an isolated dc-dc converter (DC1). The galvanic isolation between the industrial field and Arduino® UNO R3
connectors is guaranteed up to 3kV by the digital isolators and DC1.
The expansion board can be connected to either a
You can also evaluate a system consisting of an
compatible in terms of logic signals assignments..
UM3285 - Rev 1 - January 2024
For further information contact your local STMicroelectronics sales office.
NUCLEO-F401RE
X-NUCLEO-OUT07A1
Figure 1. X-NUCLEO-OUT07A1 expansion board
