Evaluation Board User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Qty. Reference Designator
4 J7, J8, J9, J12
1 D1
1 C8
2 C1, C2
4 J5, J6, J10, J11
2 R10, R11
2 POT1, POT2
1 J14
2 J13, J15
5 R7, R8, R9, R12, R16
9 C5, C6, C7, C9, C10,C11,
C14, C16, C17
1 R14
1 R15
2 R5, R6
1 R13
1 U1
1 U3
1 U2
4 J1, J2, J3, J4
8 J5, J6, J7, J8, J9, J10, J11,
J12
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Description
Standard 0.100 spacing
0603 LED: green
0.10 μF capacitor, 25 V, 0603 package
1 μF ceramic capacitor, 6.3 V, 0603 package
Inline 3-pin header
10 kΩ resistor, 0603 size
10k
Red large testpoint
Black, large test point
1.0 kΩ, 0.1 W, 0603
2.2 μF capacitor, 0805 package
24.9 Ω resistor, 1%, 0603
4.02 kΩ resistor, 1%
49.9 Ω resistor, 0603
499 Ω resistor, 0603
AD8338, low power, 80 dB VGA, low
frequency to 18 MHz
Low power, low distortion ADC driver
4 V to 28 V input LDO, 50 mA output, 5 V
Standard size end launch SMA connector
Shunt jumpers(placed over assembled headers); a
golden board is provided for reference
Rev. B | Page 7 of 8
Manufacturer Part Number
TE Connectivity 5-146269-1
Dialight 598-8060-102F
Kemet C0603C104K3RAC7411
Murata GRM033R60J105MEA2D
TE Connectivity 4-103321-5
Vishay CRCW060310K0FKEA
Vishay T73YB103KT20
Kobiconn 151-107-RC
Kobiconn 151-103-RC
KOA Speer RK73H1JTTD1001F
TDK C2012X7R1C225K125AB
Vishay CRCW060324R9FKEA
Vishay CRCW06034K02FKEB
KOA Speer RK73H1JTTD49R9F
Vishay CRCW0603499RFKEA
Analog Devices, Inc. AD8338ACPZ-R7
Analog Devices ADA4940-1ARZ
Analog Devices ADP1720ARMZ-5-R7
Cinch Connectivity 142-0701-801
Solutions
3M 969102-0000-DA
UG-559
