Figure 2
(Example of how to mount the DB5 system)
LINAK recommends that the DESKLINE DB5 system should be used in push applications - with the motor housing
®
upwards.
Placement of a monitor directly above the motor housing may cause malfunction of the monitor. Magnets inside the
motor may interrupt the picture on the monitor depending on the distance and type of monitor. If this is the case the
problem may be solved by placing an iron plate/tube or another magnetic material, somewhat larger than the motor
housing, between the motor and the tabletop.
