6.3 Pin assignment

SOCKET
Mains
Phone L
Phone R
Free Field
Patient
Response
Monitor
USB A (OUT)
Rev.
8504660 3
CONNECTOR
DC socket
Rated current international:
250 V/2,5 A
6.3 mm Mono
3.5 mm Stereo
1. +5 VDC
2. Data -
3. Data +
4. Ground
Operation Manual PILOT TEST
PIN 1
L (Live)
Ground
Ground
38
PIN 2 PIN 3
G
(Ground) (Neutral)
Signal
Signal
USB B (IN)
1. +5 VDC
2. Data -
3. Data +
4. Ground
06/11/2019
N
-
-
-
