5.1.4 Display and Control Panel
Figure 4 shows the Display and the Control Panel of the PILOT TEST.
Figure 4
Table 7 Explanation of Keys
KEY
EXPLANATION
Group
Selection of the word list for
PILOT TEST (Group 1-4)
Start / Stop
Start / Stop of PILOT TEST
Pause
Temporily stop PILOT TEST
Forward
PILOT TEST: Next word
Audiometry: Pulse tone on
Backwards
PILOT TEST: Repeat last word
Audiometry: Pulse tone off
L / R Ear
Change ear selection
Rev.
8504660
3
Operation Manual PILOT TEST
KEY
17
EXPLANATION
Menu
Set up Menu (see Section 7 of
Operating Instructions)
Enter
Store response during test
Audiometer
Starts Tone Audiometry
Loudness
Decrease
or
increase
intensity level (dB) in Tone
Audiometry mode
Frequency
Decrease
or
increase
frequency (Hz) in audiometry
mode
Tone
Signal presentation in Tone
Audiometry test (adjustable in
the User menu)
06/11/2019
of
of
