UM1724
Table 23. ARDUINO
Connector Pin
2
CN5 digital
1
8
7
6
5
CN9 digital
4
3
2
1
1. Refer to Table 10: Solder bridges
6.12

ST morpho connector

The ST morpho connector consists in male pin headers (CN7 and CN10) accessible on both
sides of the board. They can be used to connect the STM32 Nucleo board to an extension
board or a prototype/wrapping board placed on top or on bottom side of the STM32 Nucleo
board. All signals and power pins of the STM32 are available on ST morpho connector. This
connector can also be probed by an oscilloscope, logical analyzer or voltmeter.
Table 24
CN7 odd pins
Pin
1
3
5
7
9
11
13
15
17
19
21
23
25
®
connectors on NUCLEO-L476RG (continued)
Pin name
D9
D8
D7
D6
D5
D4
D3
D2
D1
D0
for details.
to Table 33 show the pin assignments of each STM32 on ST morpho connector.

Table 24. ST morpho connector on NUCLEO-F030R8

CN7 even pins
Name Name
PC10 PC11
PC12 PD2
VDD E5V
(1)
BOOT0 GND
PF6
PF7 IOREF
PA13 RESET
PA14 +3.3V
PA15 +5V
GND GND
PB7 GND
(3)
PC13 VIN
(3)
PC14
STM32 pin
PC7
PA9
PA8
PB10
PB4
PB5
PB3
PA10
PA2
PA3
CN10 odd pins
Pin Pin
2 1
4 3
6 5
8 7
- 10 9
12 11
14 13
16 15
18 17
20 19
22 21
24 23
- 26 25
UM1724 Rev 14
Hardware layout and configuration
Function
TIM3_CH2
-
-
TIM2_CH3
TIM3_CH1
-
TIM2_CH2
-
USART2_TX
USART2_RX
CN10 even pins
Name Name
PC9 PC8
PB8 PC6
PB9 PC5
AVDD U5V
GND -
PA5 PA12
PA6 PA11
PA7 PB12
PB6 PB11
PC7 GND
PA9 PB2
PA8 PB1
PB10 PB15
Pin
2
4
6
(2)
8
10
12
14
16
18
20
22
24
26
53/68
