Set-up and start-up
Alarm Pressure value
level
4
0.300 bar (225 mmHg)
5
0.400 bar (300 mmHg)
6
0.500 bar (375 mmHg)
7
0.700 bar (525 mmHg)
8 0.900 bar (675 mmHg)
9 1.000 bar (750 mmHg)
Note: Occlusion must be resolved before
the infusion is re-started. Otherwise it will
affect the measurement accuracy.
The set pressure level is shown with a P
(for pressure) and a number. In addition,
a red area shows how quickly the set
pressure alarm limit will be reached. The
"manometer" display shows the current
pressure in the system. The lower the set
pressure alarm limit level is, the larger the
red area is, the quicker this limit is reached
and a pressure alarm triggered.

Configuring service settings

7.3.5
Select Service... and press OK to con-
Q
firm.
Enter the service code and press OK
Q
to confirm.
The "Service Menu" screen is displayed.
Configuring the display language
Select Language and press OK to con-
Q
firm.
Select the language and press OK to
Q
confirm.
Setting the date and time
Select Date and press OK to confirm.
Q
Enter the day, month and year and
Q
press OK to confirm.
Select Time and press OK to confirm.
Q
Enter the time and press OK to
Q
confirm.
Setting the bolus rate
Select Bolus rate and press OK to
Q
confirm.
Set the bolus rate and press OK to
Q
confirm.
23
