PROGRAMMING

The Sterling 10 may be programmed to suit a wide variety of installations. The following pages show the programmed
options available and how to change them. Once the engineer mode has been entered, each section may be changed in
any order. As each programmable option is completed a two tone acceptance will be heard and the system will return to
engineer mode so that the next function can be programmed. A single low tone signifies programming not accepted.
9.1

Factory Defaults

The panel is pre-programmed to the factory settings shown below.
Master User Code - 1234
Limited User Code - 5678
Bell Time - 20 mins
Entry Time - 30 Secs
Exit Time - 30 Secs
Bell Delay - 0 mins
Communication Delay - 0 secs
Engineer Code - 9999
Programmable Outputs - Off
System Option 1 - Audible PA
System Option 2 - Power-up NVM Reset
System Option 3 - Alarm Digi Active Low
System Option 4 - Abort Digi Active High
Programmable Re-sets- Continuous
Service Timer - Not Configured
Keyswitch Set Configuration - Not Configured
Anti code Algorithm - 0
Set A Set Option - Timed Exit
Set B Set Option - Timed Exit
Set C Set Option - Timed Exit
Set D Set Option - Timed Exit
Final Door - 7 Seconds
The following key applies to the table below:
Entry / Exit = E Access = A
The zone types are factory set as follows.
1
e
Set A (Full)
e
Set B
e
Set C
e
Set D
9.2

Entering Engineer Mode

Enter
The fault LED will flash when the Sterling is in Engineer mode.
The day LED will flash during programming of any of the functions.
Whilst in Engineer mode, you are able to remove any covers without creating a tamper alarm.
9.3

Setting Volume Control

This volume is controlled via the adjustable volume pot on the main processor board.
1. Remove lid.
2. Set volume pot to desired volume
3. Depress a number digit on the keypad to check desired volume has been reached.
4. Replace cover.
In an alarm condition the volume control is overridden and the speakers will operate at full volume.
NOTE: Each RKP has its own volume control pot.
Page 22
User Log Reset Disabled
User Log Reset
Internal Sounder Only On Tamper Activation
No Siren On Line Fail
No Panel Set On AC Fail
PA Digi Active Low
Fire Digi Active Low
Confirmed Digi Active Low
Open/Close (Set) Digi Active Low
Service Timer Warning On Expire
Anti code reset disabled
Immediate = I
Zone Number
2 3 4 5
a I I I
a I I I
a I I I
a I I I
6 7 8
I I I
I I I
I I I
I I i
