HODEDAH

Assembly Instructions

This instruction booklet contains important safety information, please read and keep for future reference.
ITEM # HIK 92-T (MOP)
KITCHEN CABINET
FRONT VIEW
Product Dimensions : Height 70.9'' x Width 23.9'' x Depth 15.75''
www.Hodedah.com
2 people
90 mins
1 YR LTD
1 Box
REAR VIEW
1 | Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIK 92-T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hodedah HIK 92-T

Summary of Contents for Hodedah HIK 92-T

  • Page 1 HODEDAH Assembly Instructions 2 people This instruction booklet contains important safety information, please read and keep for future reference. 90 mins ITEM # HIK 92-T (MOP) 1 YR LTD KITCHEN CABINET 1 Box FRONT VIEW REAR VIEW Product Dimensions : Height 70.9'' x Width 23.9'' x Depth 15.75'' 1 | Page www.Hodedah.com...
  • Page 2 WARRANTY Hodedah warrants this product to be free from defect in materials and workmanship and agrees to remedy and such defect. This warranty covers one year from the date of original purchase. This is solely limited to replacement of defective parts and no assembly for labor is included.
  • Page 3 HODEDAH Let's get started... Helpful hints, read before beginning assembly Make sure you receive all boxes. if your item is packed in one box, box count will read 1 of 1, likewise if your item is packed in two boxes, box count will read 1 of 2 and second box will read 2 of 2.
  • Page 4 HODEDAH Hardware List M8X25MM M3.5X16MM NAIL 5/8 M4X32MM M6X50MM M4X38MM MOON Allen Key HANDLE 96MM M4X20MM Minifix Cap Minifix Nut Minifix Bolt 100 Metal Leg Shelf Support Hinges 5/8 Drawer Slide ''14 Drawer Slide ''14 Important 1. Before you throw the package, please use the Check Box to identify the parts and hardware to ensure that you have everything you need.
  • Page 5 HODEDAH Parts List 800x290x15mm 1214x288x15mm 1214x288x15mm 768x287x15mm 768x287x15mm 800x30x30mm 596x394x15mm 596x394x15mm 1235x398x2.5mm 800x400x15mm 604x398x15mm 604x398x15mm 768x70x15mm 768x398x15mm 800x398x15mm 400x394x15mm 400x394x15mm 794x196x15mm 5 | Page www.Hodedah.com...
  • Page 6 HODEDAH Parts List 350x96x15mm 712x96x15mm 741x350x2.5mm 629x398x2.5mm 6 | Page www.Hodedah.com...
  • Page 7 HODEDAH The Breakdown... 7 | Page www.Hodedah.com...
  • Page 8 HODEDAH Step 1 WOOD DOWEL M8x25MM SHELF SUPPORT 1. Insert 22 x wood dowels (A) into panels (2,3,4,11,12 & 13) using plastic hammer. 2. Insert 8 x shelf support (J) into panels (2,3,11 & 12). 8 | Page www.Hodedah.com...
  • Page 9 HODEDAH Step 2 CB SCREW M3.5X16MM HINGES 5/8 MINIFIX BOLT DRAWER SLIDE ''14 BOTTOM VIEW 1. Insert 10 x minifix bolt (I2) into panel (10 & 6) with screwdriver. 2. Insert 8 x hinges (K) into panels (7,8,16 & 17) 's non-thru holes.Then tighten 16 x cb screws M3.5x16mm (B) with screwdriver.
  • Page 10 HODEDAH Step 3 CSK CAP M6X50MM CB SCREW M4X20MM ALLEN KEY MINIFIX CAP MOON HANDLE - 96MM 1. Place 4 x moon handle (H1) to panel (7,8,16 & 17) front and tighten 8 x cb screws M4x20mm (H2). 2. Attach panel (4) to panel (2 & 3) by inserting dowel (A) onto non-thru holes at panel (2 & 3).
  • Page 11 HODEDAH Step 4 CSK CAP M6X50MM MINIFIX CAP ALLEN KEY MINIFIX NUT 1. Attach panel (6) to panel (1 & 10) with 6 x minifix nut (I1) using allen key (G). Cover the minifix holes by using 6 x cap (I3).
  • Page 12 HODEDAH Step 5 CB SCREW M3.5X16MM MOON HANDLE - 96MM CB SCREW M4X32MM NAIL 5/8 CB SCREW M4X38MM DRAWER SLIDE ''14 1. Place 2 x panels (19) next to each side of panel (18 & 20). (As Shown). Then tighten 8 x screws (E) to the edges of panel (18 &...
  • Page 13 HODEDAH Step 6 CB SCREW M3.5X16MM MINIFIX NUT ALLEN KEY 100 METAL LEG MINIFIX CAP 1. Connect panel (11 & 12) to panel (10) with 4 x minifix nut (I1) using allen key (G). Cover the minifix holes by using 4 x cap (I3).
  • Page 14 HODEDAH Step 7 1. Slide the drawer box (18) by slotting the rollers at each end of drawer slide (M2) onto the rail of drawer slide (M1) fixed at side panel (11 & 12). Then slide the drawer in slowly.
  • Page 15 HODEDAH Step 8 NAIL 5/8 1. Fix 66 x nails (C) into panel (9 & 22) using hammer. 15 | Page www.Hodedah.com...
  • Page 16 HODEDAH Step 9 Final step... CB SCREW M3.5X16MM 1. Attach panels (7 & 8) to panel (2 & 3) with hinges (K) by using 8 x cb screws M3.5x16mm (B) with screwdriver. 2. Attach panels (16 & 17) to panel (11 & 12) with hinges (K) by using 8 x cb screws M3.5x16mm (B) with screwdriver.
  • Page 17 HODEDAH Job Complete... Enjoy & Thank you for purchasing from Hodedah! 17 | Page www.Hodedah.com...
  • Page 18 Failure to detach this restraint before moving furniture may result in injury and damage. If the safety kit is not in the box, please contact our consumer service team at Tel. 1 (718) 456 0505 or Email Support@Hodedah.com in order to obtain one before using the furniture.
  • Page 19 HODEDAH FITTING OF ANTI-TIP SAFETY STRAP STEP 1: Attach the mounting bracket to the furniture in the solid part below the top panel a few inches away from the side of the unit. Screw through the smallest hole of STEP 2:...
