Summary of Contents for Hodedah HIK 69-MOP
- Page 1 Hodedah www.hodedah.com support @hodedah.com HIK 69-MOP " X D17 " X H37 "...
- Page 2 Hodedah www.hodedah.com support @hodedah.com PART & HARDWARE LIST PLASTIC DOWEL M8 X 25MM HANDLE SV 48 (SILVER) CB SCREW M3 X 12MM P/H SCREW M4 X 24MM CB SCREW M3.5 X 12MM P/H SCREW M4 X 40MM CB SCREW M3.5 X 16MM...
- Page 3 Hodedah www.hodedah.com support @hodedah.com - This product contains small components, please ensure that they are kept away from small children. - THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. DO NOT RETURN PRODUCT TO THE STORE.
-
Page 4: Helpful Hints
- Never push, drag or pull your furniture (especially on carpet). Warranty Information Hodedah warrants this product to be free from defects in material and workmanship agrees to remedy any such defect. This warranty covers one year from the date of original purchase. This is solely limited to be repair or replacement of defective parts and no assembly labor is included. - Page 5 Hodedah www.hodedah.com support @hodedah.com STEP 1 PLASTIC DOWEL M8 X 25MM PVC SHELF SUPPORT LEFT VIEW LEFT VIEW LEFT VIEW RIGHT VIEW RIGHT VIEW RIGHT VIEW - Insert 32 x Plastic dowel (A) into Panels (1), (2) (3), (4), (5), (6), (7), (8), (9) & (10) using a plastic hammer.
-
Page 6: Bottom View
Hodedah www.hodedah.com support @hodedah.com STEP 2 CB SCREW M3.5 X 12MM HANDLE SV 48 (SILVER) P/H SCREW M4 X 24MM DOOR SUPPORT SPRING DRAWER SLIDE 14" MINIFIX 5654 BOTTOM VIEW LEFT VIEW RIGHT VIEW FRONT VIEW - Assemble 2 x Drawer slide (O1) to Panel (1) & (5) with 6 x CB Screw M3.5 x 12m (C) using Philips head screwdriver. - Page 7 Hodedah www.hodedah.com support @hodedah.com STEP 3 CB SCREW M3 X 12MM CSK CAP M6 X 40MM HANDLE SV 48 (SILVER) 902 MAGNET PLATE P/H SCREW M4 X 24MM 902 MAGNET ALLEN KEY ALLUMINIUM PIPE (384MM) LEFT VIEW BACK VIEW RIGHT VIEW...
- Page 8 Hodedah www.hodedah.com support @hodedah.com STEP 4 ALLEN KEY CSK CAP M6 X 40MM - Attach Panel (5) & (6) into Panel (4). Insert 2 x Csk Cap M6 x 40 (G), tighten with Allen key (Q) & insert 2 x Cap (L).
- Page 9 Hodedah www.hodedah.com support @hodedah.com STEP 5 CB SCREW M3.5 X 16MM ABS SQUARE LEG (H100MM) CSK CAP M6 X 40MM ALLEN KEY - Slot 2 x Panel (11) into Panel (4), (8), (9) & (10) groove. - Attach Panel (12) to Panel (4), (8), (9) & (10) with 8 x CSK Cap M6 x 40mm (G), tighten with Allen key (Q).
- Page 10 Hodedah www.hodedah.com support @hodedah.com STEP 6 CB Screw M4 X 25MM HANDLE SV 48 (SILVER) P/H SCREW M4 X 40MM CB Screw M4 X 35MM MINIFIX 5654 ALLEN KEY & - Slot 1 x Panel (13) into Panel (4) & (10) groove.
- Page 11 Hodedah www.hodedah.com support @hodedah.com STEP 7 DRAWER SLIDE 14" CB SCREW M3.5 X 12MM POWER NAIL " LEFT RIGHT - Fix 4 x Drawer slide 14" (O2) into Panel (17) using 12 x CB Screw M3.5 x 12mm (C) & tighten with Philip head screwdriver.
-
Page 12: Job Complete
Hodedah www.hodedah.com support @hodedah.com STEP 8 BOTTOM 20 & 21 20 & 21 - Press & insert the Door support spring (I) at the panel (20) & (21) top into the hole at bottom of Panel (5). - Press the Door support spring (I) at the panel (20) & (21) base & insert into the hole at panel (12).
