LINEA PRO 7 PLUS USER MANUAL

Power On Linea Pro 7 Plus

After the iOS device is attached to the Linea Pro 7 Plus and the
application software is installed, you can turn on the unit.
1. With the unit turned off, press one of the Scan buttons on the
side of the unit. When the unit is active, the LED on the top side
illuminates blue, based on the battery level.
2. Unlock the iOS device screen.
Note
When the Linea Pro 7 Plus is left idling for an extended period, the
power is automatically turned off to preserve the charge on the internal
battery pack. If turned off, the unit is in sleep mode immediately.

Scan Barcodes

The scan engine in the Linea Pro 7 Plus 1D model supports one-
dimensional (1D) barcode symbols. The 2D model scan engine
supports one-dimensional (1D) and two-dimensional (2D) barcode
symbols. The effective reading distance of the barcode reader varies
based on the barcode size. For example, 15-20 cm (5.9-7.9 inches).
These types of scanning modes are supported:
• Single scan
• Multi-scan
• Motion detect
• Multi-scan without duplicates
To scan a barcode
1. Press and hold the Scan button on either side of the unit to
activate the Linea Pro 7 Plus.
2. Position the scan head as close to the center of the barcode
label by aiming the illumination box over the outer edges of
the barcode.
3. Pull the unit back slowly back or forth, increasing the distance
between the barcode and scan head, until the barcode is read
by the scanner. Data is displayed on the iOS device.
Read Contactless Cards
(Optional)
The contactless card reader incorporates several RFID formats
depending on your Linea Pro 7 Plus model.
To use the contactless card reader
1. Press the Scan button to activate the unit.
2. Place the RFID tag/card over the receiver/transmitter as
indicated by the RFID label.
Note
Data is sent from the Linea Pro 7 Plus contactless card reader to the
iOS device.
