Calibration Procedure - EGR RollTrac Owner's Manual

1. Start the vehicle in an open area (note exhaust fumes are a health and safety hazard!).
2. Open the tailgate.
3. Ensure the motor clutch is engaged.
4. Ensure car doors are unlocked and disable auto-locking during calibration procedure.
Press the two side rail buttons simultaneously for 10 seconds to START calibration mode.
WARNING: Keep obstructions clear of cover during calibration mode.
1
• Cover will open and close twice automatically.
• The cover internal LED light will pulse slowly during calibration and stop pulsing when
calibration is complete.
START OF CALIBRATION
1
4
RT0001 Date: 08/04/20

Calibration Procedure

2
2
5
Issue: 5 Page: 5 of 12
3
2 SECOND PULSE
DURING CALIBRATION
END OF CALIBRATION
!
4
10 SECONDS
PULL
3
6
