Component Locations

A. Central lift point
B. Air cleaner
C. Rear leveling jacks (2)
D. Priming chamber
E. Pump outlet (discharge) port
F. Fuel pre-filter
G. Engine oil drain
Owner's Manual for Wet-Prime Trash Pumps
N
L
K
M
Figure 2-3. Left Side (6 Inch Pump Shown)
A
B
F
H
G
I
J
H. Battery
I. Fuel filter (main)
J. Coolant drain
K. Engine oil dipstick
L. Engine oil filter
M. Front leveling jack
N. Tie down ring
